Westgate 20W 1600-1720LM 3000K/4000K/5000K LED Commercial Recessed Light CRLC4-20W-MCT-A-D

Product Overview

The Westgate CRLC4-20W-MCT-A-D is a 20W LED recessed downlight that produces 1,720 lumens with selectable color temperatures of 3000K, 4000K, or 5000K. It accepts 120–277V input and supports 0–10V dimming.

Suitable for general and accent recessed lighting in commercial and residential ceilings, the fixture is intended for installations where a compact, energy-efficient downlight with selectable CCT is required.

Key Features

• 20W power draw with 1,720 lumens output (86 lm/W efficacy)
• Selectable color temperature: 3000K, 4000K, 5000K set at install
• Wide voltage range: 120–277V
• 0–10V dimming
• UPC: 845060075526

Function and intended use

This recessed LED downlight provides general and accent illumination for commercial and residential ceilings. Typical uses include ceiling downlighting and retrofit or new-install recessed applications.

• Common applications: commercial ceiling downlighting, residential recessed lighting, corridors and lobbies, retrofit projects

Electrical input and dimming

The fixture accepts 120–277V input. It supports 0–10V dimming for connection to compatible dimming controls.

• Input voltage: 120–277V
• Dimming control: 0–10V (requires compatible wiring and controls)

Light output and color temperature

Rated at 1,720 lumens from 20W, the luminaire reports approximately 86 lumens per watt. Color temperature is selectable at installation between 3000K, 4000K, and 5000K.

• Light output: 1,720 lumens
• Efficacy: 86 lm/W (reported)
• Selectable CCTs: 3000K / 4000K / 5000K

Installation and compatibility notes

Confirm ceiling cutout dimensions and whether a compatible rough‑in or retrofit housing is required for your project. Selectable CCT and 0–10V dimming require access to the fixture during installation and appropriate wiring for dimming controls.

• Verify ceiling cutout and housing compatibility before ordering
• Selectable CCT is set at installation
• 0–10V dimming requires compatible wiring and controls

Before You Order

Verify ceiling cutout dimensions and whether a compatible rough‑in or retrofit housing is required.

• Confirm model: CRLC4-20W-MCT-A-D
• Verify ceiling cutout and housing compatibility
• Ensure compatible wiring and controls for 0–10V dimming
