QO2100VH - Square D QO 100 Amp 2-Pole Plug-In Miniature Circuit Breaker, 120/240V, 22kA Interrupt Rating, HACR Rated

Product Overview

The QO2100VH is a Square D QO series plug‑in miniature circuit breaker rated 100 amps for 120/240V single‑phase service.

It features a 22 kA interrupting rating and is HACR rated (Heating, Air Conditioning, Refrigeration).

Key Features

• 100 Amp, 2‑pole plug‑in breaker for 120/240V systems
• 22 kA interrupting rating
• HACR rated for HVAC and refrigeration equipment
• Square D QO series form factor (plug‑in miniature)

Function and Purpose

This breaker provides overcurrent protection for branch circuits and loads requiring up to 100 amps on 120/240V single‑phase systems. As a 2‑pole device, it simultaneously interrupts both ungrounded conductors when a fault or overload occurs.

• Protects conductors and connected equipment from overcurrent conditions
• 2‑pole design ensures simultaneous disconnect of both hot legs

Electrical Ratings and Performance

Use this model where the system requires a 100 A trip rating and a 120/240V nominal voltage. The breaker has a 22 kA interrupting rating, indicating the maximum fault current it is rated to safely interrupt.

• Ampacity: 100 A
• Voltage: 120/240V
• Interrupting rating: 22 kA

Panel Compatibility and Form Factor

The QO2100VH is a plug‑in miniature breaker in the Square D QO series form factor. It is intended for installation in panels that accept Square D QO plug‑in breakers.

• Plug‑in QO series form factor
• Designed for use with compatible Square D QO panelboards (confirm panel model for mechanical fit)

Typical Applications

This breaker is HACR rated, making it suitable for protecting circuits that serve heating, air conditioning, and refrigeration equipment where HACR listing is required.

Beyond HVAC loads, it can be used where a 100 A, 2‑pole protective device with a 22 kA interrupt rating is appropriate.

• HVAC and refrigeration circuits (HACR rated)
• General 120/240V branch circuit protection up to 100 A

Ordering and Verification

Confirm the exact model number and verify that your panel accepts Square D QO plug‑in breakers before ordering. This listing is for the single SKU QO2100VH.

• Confirm panel compatibility (Square D QO series)
• Verify system voltage and required ampacity (120/240V, 100 A)
• Request a quote for pricing and availability

Before You Order

Confirm the model number and quantity required before ordering. Verify the breaker will fit your panel and that the electrical ratings match your application.

• Confirm panelboard accepts Square D QO plug‑in breakers
• Verify system is 120/240V and requires a 100 A, 2‑pole device
• Request a quote for pricing and availability

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for QO2100VH - Square D QO 100 Amp 2-Pole Plug-In Miniature Circuit Breaker, 120/240V, 22kA Interrupt Rating, HACR Rated. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
