Premium Lighting Up & Down Wall Pack SUG3 120W 150lm/W 18000lm, Daylight Photocell, 10kV Surge, Bronze

Product Overview

The Premium Lighting Up & Down Wall Pack SUG3 120W 150lm/W 18000lm supplies 4 selectable wattages (60W-90W-100W-120W) and 3 selectable color temperatures from a single fixture, set with onboard switches at install time. At full power it produces 18,000 lm (150 lm/W). A factory daylight photocell switches the fixture at dusk and dawn. Building-mounted exterior lighting for entries, walls, and perimeter coverage.

Key Features

• One SKU replaces 4 fixture stock numbers, so a single unit covers 60W through 120W jobs and trims truck stock
• CCT switch covers 4000K through 5700K on one unit, ending mixed-tone ceilings on phased jobs
• 150 lm/W output helps qualify wattage-reduction line items on retrofit calcs
• Dusk-to-dawn photocell runs the fixture only during dark hours, with no timer to program
• Up-and-down distribution washes the wall above and below the fixture for architectural facades
• 10 kV surge protection rides out line transients common on outdoor branch circuits
• DLC listing supports utility rebate applications where programs apply

Technical Specifications

Applications

Common applications include:

• loading docks
• alley and perimeter walls
• service yards
• building entries

Compatibility and Installation Notes

Confirm junction-box position and wall construction; photocell models need unobstructed sky exposure to cycle correctly.

Order the SUG3 series led wall pack from Lumera Electric for exterior wall projects.
