Nora Lighting NHAPIC-3S15L12755DP 3" Apollo Square IC Airtight New Construction Housing w/ 1.25" to 1.625" Ceiling Collar, 1000lm / 10W, 2700K, Flood Optic, 120V; Phase Dimming

Product Overview

The Nora Lighting NHAPIC-3S15L12755DP is a 3-inch square recessed housing for new-construction ceilings. It is IC airtight and specified for 1000 lm at 10 W on 120 V, with a 2700 K color temperature and flood optic.

Its ceiling collar accommodates finished ceiling thicknesses from 1.25 to 1.625 inches. The housing supports phase dimming when paired with a phase-control dimmer rated for the load.

Key Features

• 3-inch square aperture with flood optic
• IC airtight housing can contact ceiling insulation
• New-construction configuration for installation before the ceiling is finished
• 1000 lm output at 10 W, 120 V and 2700 K
• Ceiling collar range: 1.25 to 1.625 inches
• Phase dimming

Output and Light Distribution

The NHAPIC-3S15L12755DP delivers 1000 lm at 10 W on 120 V. Its 2700 K color temperature and flood optic define the listed light output and distribution.

New-Construction and Insulation Use

This is a new-construction housing intended for installation before the ceiling is finished. Its IC airtight rating means the housing can be in direct contact with ceiling insulation.

Ceiling Thickness and Collar Range

The adjustable ceiling collar fits finished ceiling thicknesses from 1.25 to 1.625 inches. Check the ceiling thickness against this range when specifying the housing.

Phase Dimming

The housing supports phase dimming. Use a phase-control dimmer rated for the load.

Before You Order

Confirm the finished ceiling thickness falls within the 1.25-to-1.625-inch collar range. For dimming, select a phase-control dimmer rated for the load.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Nora Lighting NHAPIC-3S15L12755DP 3" Apollo Square IC Airtight New Construction Housing w/ 1.25" to 1.625" Ceiling Collar, 1000lm / 10W, 2700K, Flood Optic, 120V; Phase Dimming. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
