Morris 96104 Insulation Piercing Connector, 750 MCM Main / 10 AWG Tap

(No Ratings)
SKU: 96104
Price: $58.12
Free shipping on orders over $1,500

Description

Product Overview

The Morris 96104 is an above-ground insulation piercing connector for tapping a 10–14 AWG conductor from a 750 MCM–3/0 AWG main. Its piercing teeth connect through conductor insulation, so the conductors do not need to be stripped.

The connector has one double shear-head bolt, which breaks off at 80 in-lb. It is designed for copper or aluminum conductors and has tin-plated copper teeth in a fiber-reinforced thermoplastic body.

Key Features

  • Connects a 750 MCM–3/0 AWG main to a 10–14 AWG tap without stripping the conductors.
  • One double shear-head bolt breaks off at 80 in-lb; the bolt head takes a 1/2-inch socket.
  • For copper or aluminum conductors; intended for above-ground installation.
  • Sealant gel protects against oxygen and water when the connector is properly installed.

How the Morris 96104 Makes a Tap Connection

The Morris 96104 uses insulation-piercing technology to connect a tap conductor to a main without stripping the conductors. Tin-plated copper teeth pierce the insulation inside the connector body.

Main and Tap Conductor Compatibility

This connector accepts a main conductor from 750 MCM to 3/0 AWG and a tap conductor from 10 to 14 AWG. It is specified for copper or aluminum conductors.

Connector Materials and Protection

The 96104 has tin-plated copper piercing teeth, a fiber-reinforced thermoplastic body, and a galvanized steel bolt. Sealant gel protects against oxygen and water when the connector is properly installed.

Applications and Installation Details

The connector is intended for above-ground tapping, including overhead services, above-grade URD, street lighting, gutter taps, and non-tension split-bolt replacement. It is specified for insulated or bare mains.

  • Insert the tap conductor fully into the end cap, place the connector on the main, and tighten the 1/2-inch shear-head bolt with a closed-end wrench or socket until the head breaks off at 80 in-lb.
  • The product information states that installation on energized conductors is possible, but the tap must not be under load.

Before You Order

Confirm that the main and tap conductor sizes fall within the connector's specified ranges and that the intended connection is above ground.

  • The tap must not be under load during installation.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 96104 Insulation Piercing Connector, 750 MCM Main / 10 AWG Tap. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.

Specifics

BrandMorris
Catalog Number96104
Product TypeInsulation piercing connector
Run (Main) Range750 MCM–3/0 AWG
Tap Range10–14 AWG
Conductor CompatibilityCopper or aluminum
Bolt quantity1 double shear-head bolt
Bolt break-off torque80 in-lb
Bolt Head Size1/2 inch
Teeth materialTin-plated copper
Housing MaterialFiber-reinforced thermoplastic
Bolt materialGalvanized steel
InstallationAbove ground
