Morris 94434 Copper Short-Barrel Compression Splice, 400 MCM

Product Overview

The Morris 94434 is an inline short-barrel compression (butt) splice engineered to join two 400 MCM copper conductors end-to-end.

Constructed from high-conductivity seamless copper with electro-tin plating, it features a beveled entry, printed crimp marks and a blue color-coded die index. It is UL 486AB listed for applications through 35 kV.

Key Features

• Designed for two 400 MCM copper conductors (inline butt splice)
• High-conductivity seamless copper construction
• Electro-tin plating for improved corrosion resistance
• Beveled entry for easier conductor insertion
• Blue color-coded die index and printed crimp marks on the barrel
• UL 486AB listed through 35 kV

What this splice does

The Morris 94434 is an inline compression (butt) splice intended to join two 400 MCM copper conductors end-to-end. It provides a mechanical and electrical connection when crimped with the appropriate die.

• Use: splice two 400 MCM copper conductors
• Configuration: short-barrel inline butt splice

Materials and corrosion protection

The barrel is formed from high-conductivity seamless copper and receives an electro-tin plating. The tin plating improves corrosion resistance while maintaining electrical conductivity.

• Base material: seamless copper
• Finish: electro-tin (tin-plated)

Safety and electrical rating

This splice is UL 486AB listed for use through 35 kV, indicating compliance with the UL standard referenced for electrical connectors of this type.

• Listing: UL 486AB
• Voltage rating: through 35 kV

Installation and crimping

Insert one conductor into each end of the barrel to the center stop, then crimp both sides using the blue-coded die. The barrel has a beveled entry to ease conductor insertion and printed crimp marks to help position the die.

• Beveled entry eases conductor insertion
• Crimp with Blue-coded die per printed marks
• Insert to center stop before crimping

Conductor compatibility

This specific SKU is sized for 400 MCM copper conductors only. Confirm conductor material and size before use.

• Compatible conductor size: 400 MCM
• Conductor material supported: copper (as specified)

Before You Order

Confirm the model number and quantity required before ordering. This SKU is specifically for splicing two 400 MCM copper conductors; do not substitute for other conductor sizes or materials.

• Verify conductor size (400 MCM) and material (copper) prior to purchase
• Ensure you have the correct blue-coded die and crimp tooling for installation
• Confirm required certification or project specifications reference UL 486AB through 35 kV

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 94434 Copper Short-Barrel Compression Splice, 400 MCM. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
