Morris 94432 Copper Short-Barrel Compression Splice, 350 MCM

(No Ratings)
SKU: 94432
Price: $9.90
Free shipping on orders over $1,500

Description

Product Overview

The Morris 94432 is a copper short-barrel compression splice for joining two 350 MCM copper conductors end to end. Its inline butt-splice design connects one conductor at each end of the barrel.

The seamless copper body has electro-tin plating, a beveled entry, and a red color-coded die index. The splice is UL 486AB Listed for applications through 35kV.

Key Features

  • Joins two 350 MCM copper conductors inline
  • Seamless copper construction with electro-tin plating
  • Short barrel with beveled conductor entry
  • Red color-coded die index and crimp marks printed on the barrel
  • UL 486AB Listed through 35kV

What the Morris 94432 Splice Connects

The Morris 94432 connects two 350 MCM copper conductors end to end. Its short-barrel, inline butt-splice format accepts one conductor from each end.

Copper Barrel and Red Die Index

The splice is made from high-conductivity seamless copper with electro-tin plating. A beveled entry supports conductor insertion, while the barrel carries a red color-coded die index and printed crimp marks.

Inline Use and UL Listing

The 94432 is described for inline splicing of two 350 MCM copper conductors in feeders, services, and equipment wiring. It is UL 486AB Listed for applications through 35kV.

Conductor Insertion and Crimping

The documented installation arrangement places one conductor into each end of the barrel to the center stop, then crimps both sides with the red-coded die.

Before You Order

Confirm the Morris 94432 model number and quantity required before ordering.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 94432 Copper Short-Barrel Compression Splice, 350 MCM. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.

Specifics

BrandMorris
Catalog Number94432
Product TypeCopper short-barrel compression splice
Wire Size350 MCM
ConfigurationInline butt splice
BarrelShort barrel
MaterialHigh-conductivity seamless copper
PlatingElectro-tin plated
Die color indexRed
CertificationsUL 486AB Listed through 35kV
