Morris 94360 Copper Long-Barrel Compression Lug, 3/0 AWG, 3/8" Stud, 2-Hole

Product Overview

The Morris 94360 is a tin-plated, seamless-copper long-barrel compression lug intended to terminate 3/0 AWG stranded conductors to a 3/8" stud using a 2-hole mounting tongue.

It has a color-coded (orange) die index and printed crimp marks, includes an inspection window, and is UL 486AB listed through 35 kV.

Key Features

• Seamless copper construction with electro-tin plating
• Long barrel with printed crimp marks and inspection window
• Color-coded (orange) die index printed on the barrel
• 2-hole mounting tongue sized for a 3/8" stud
• UL 486AB listed through 35 kV

What this lug does

The Morris 94360 terminates a 3/0 AWG stranded copper conductor and provides a 2-hole tongue sized for a 3/8" stud. The long-barrel design accommodates multiple crimps and includes an inspection window to check conductor insertion.

• Purpose: terminate 3/0 AWG stranded copper conductors
• Mounting: 2-hole tongue for bolted connection to a 3/8" stud
• Features: long barrel and inspection window

Installation and crimping

Strip the conductor to the barrel depth, insert fully so the conductor can be seen via the inspection window, and crimp using the die indicated by the orange color code printed on the barrel. Bolt the tongue to the 3/8" stud using appropriate hardware.

• Strip conductor to barrel depth and verify insertion through inspection window
• Use the orange-coded crimp die indicated on the barrel

Materials and listing

Body material is seamless copper with electro-tin plating. The part is listed to UL 486AB through 35 kV.

• Material: seamless copper, electro-tin plated
• Listing: UL 486AB through 35 kV

Conductor and stud compatibility

This SKU is specified for stranded 3/0 AWG copper conductors and a 3/8" stud. The orange die color code printed on the barrel identifies the matching crimp die size.

• Conductor size: 3/0 AWG (stranded)
• Stud size: 3/8"
• Die color code: Orange

Before You Order

Verify the lug matches the conductor and stud sizes in your application (3/0 AWG stranded to 3/8" stud).

• Confirm conductor is stranded 3/0 AWG copper
• Confirm mating stud is 3/8"
• Have the appropriate orange-coded crimp die available for termination
