Morris 91159 Copper Neutral/Ground Bar, 3-Circuit, #14-#2 AWG
Morris 91159 Copper Neutral/Ground Bar, 3-Circuit, #14-#2 AWG
Regular price
$10.84
Regular price
Sale price
$10.84
SKU:91159
Quantity
Couldn't load pickup availability
Morris's 91159 is a copper neutral/ground bar with 3 circuits (5 total holes), each accepting a #14-#2 AWG conductor. Machined from copper for copper conductors only, it is range-taking and rated 600V.
Key Features
- Copper Construction
- Rated for Copper Conductors Only
- 3-Circuit Configuration (5 Total Holes)
- Range-Taking, #14-#2 AWG Wire Range
- Rated 600V
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 91159 |
| Type | Copper Neutral / Ground Bar |
| Material | Copper |
| Wire Range | #14-#2 AWG |
| Circuits | 3 |
| Total Holes | 5 |
| Length | 2.00" |
| Conductor Compatibility | Copper Only |
| Voltage | 600V |
| Mounting Hole Positions | 1 & 5 |
Applications
Used to terminate and common multiple grounded (neutral) or grounding (equipment-ground) conductors in panelboards, load centers, meter sockets, and enclosures, with 3 circuits rated for #14-#2 AWG conductors.
Installation
Mount the bar to the enclosure at the provided mounting hole position(s), land one conductor per port, and tighten each set screw to the conductor.
