Morris 91155 Copper Neutral/Ground Bar, 12-Circuit, #14-#4 AWG
Morris 91155 Copper Neutral/Ground Bar, 12-Circuit, #14-#4 AWG
Regular price
$20.86
Regular price
Sale price
$20.86
SKU:91155
Quantity
Couldn't load pickup availability
Morris's 91155 is a copper neutral/ground bar with 12 circuits (14 total holes), each accepting a #14-#4 AWG conductor. Machined from copper for copper conductors only, it is range-taking and rated 600V.
Key Features
- Copper Construction
- Rated for Copper Conductors Only
- 12-Circuit Configuration (14 Total Holes)
- Range-Taking, #14-#4 AWG Wire Range
- Rated 600V
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 91155 |
| Type | Copper Neutral / Ground Bar |
| Material | Copper |
| Wire Range | #14-#4 AWG |
| Circuits | 12 |
| Total Holes | 14 |
| Length | 4.43" |
| Conductor Compatibility | Copper Only |
| Voltage | 600V |
| Mounting Hole Positions | 1 & 14 |
Applications
Used to terminate and common multiple grounded (neutral) or grounding (equipment-ground) conductors in panelboards, load centers, meter sockets, and enclosures, with 12 circuits rated for #14-#4 AWG conductors.
Installation
Mount the bar to the enclosure at the provided mounting hole position(s), land one conductor per port, and tighten each set screw to the conductor.
