Morris 91153 Copper Neutral/Ground Bar, 5-Circuit, #14-#4 AWG
Morris 91153 Copper Neutral/Ground Bar, 5-Circuit, #14-#4 AWG
Regular price
$10.48
Regular price
Sale price
$10.48
SKU:91153
Quantity
Couldn't load pickup availability
Morris's 91153 is a copper neutral/ground bar with 5 circuits (7 total holes), each accepting a #14-#4 AWG conductor. Machined from copper for copper conductors only, it is range-taking and rated 600V.
Key Features
- Copper Construction
- Rated for Copper Conductors Only
- 5-Circuit Configuration (7 Total Holes)
- Range-Taking, #14-#4 AWG Wire Range
- Rated 600V
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 91153 |
| Type | Copper Neutral / Ground Bar |
| Material | Copper |
| Wire Range | #14-#4 AWG |
| Circuits | 5 |
| Total Holes | 7 |
| Length | 2.25" |
| Conductor Compatibility | Copper Only |
| Voltage | 600V |
| Mounting Hole Positions | 1 & 7 |
Applications
Used to terminate and common multiple grounded (neutral) or grounding (equipment-ground) conductors in panelboards, load centers, meter sockets, and enclosures, with 5 circuits rated for #14-#4 AWG conductors.
Installation
Mount the bar to the enclosure at the provided mounting hole position(s), land one conductor per port, and tighten each set screw to the conductor.
