Morris 90992 Offset Solid Pin Terminal, 500 MCM Wire / 350 MCM Pin

Product Overview

The Morris 90992 is an offset solid pin terminal connector that adapts a 500 MCM conductor to a 350 MCM solid pin. The tin‑plated aluminum barrel is pre‑filled with oxide inhibitor and the product ships with an EPDM insulating cover.

Includes die index and crimp marks on the barrel and is rated for 600 V.

Key Features

• Offset solid pin design for adapting 500 MCM conductors to a 350 MCM pin
• Tin‑plated aluminum barrel compatible with aluminum and copper conductors
• Barrel pre‑filled with oxide inhibitor
• Die index and crimp marks on the barrel
• Supplied with EPDM insulating cover
• Rated 600 V

What this terminal does

The Morris 90992 terminates a 500 MCM conductor to a 350 MCM solid pin, providing an electrical connection suitable for equipment designed to accept a 350 MCM pin.

• Adapts 500 MCM conductor to a 350 MCM solid pin
• Intended to land aluminum or copper conductors where a 350 MCM pin is used

Materials and finish

The barrel is aluminum with a tin plating. The barrel is pre‑filled with an oxide inhibitor. An EPDM insulating cover is supplied with the terminal.

• Barrel: Aluminum, tin‑plated
• Protective filler: Oxide inhibitor (pre‑filled in barrel)
• Insulation: EPDM cover (supplied)

Installation notes

Die index and crimp marks are provided on the barrel to identify appropriate crimp locations. The product description identifies typical installation steps but does not specify tools or crimp force.

• Die index and crimp marks are present on the barrel
• EPDM cover supplied to insulate the completed termination

Typical applications

Commonly used when a 500 MCM conductor must be terminated to equipment that accepts a 350 MCM solid pin, such as breakers, switches, panelboards, and lug terminals.

• Breakers
• Switches
• Panelboards
• Lug terminals and equipment pins sized for 350 MCM

Before You Order

Verify the 500 MCM to 350 MCM sizing and that a tin‑plated aluminum terminal is appropriate for your conductor and equipment.

• Confirm receiving equipment accepts a 350 MCM solid pin
• Plan to use a crimping tool and die compatible with the terminal's die index and crimp marks
