Morris 90990 Offset Solid Pin Terminal, 350 MCM Wire / 250 MCM Pin

Product Overview

The Morris 90990 is an offset solid pin terminal connector for terminating a 350 MCM aluminum or copper conductor to a 250 MCM solid pin.

Its tin-plated aluminum barrel is pre-filled with oxide inhibitor and marked with die index and crimp marks. An EPDM insulating cover is supplied.

Key Features

• Offset solid pin design adapts a 350 MCM conductor to a 250 MCM pin.
• For aluminum or copper conductors; tin-plated aluminum barrel.
• Barrel is pre-filled with oxide inhibitor and has die index and crimp marks.
• Supplied with an EPDM insulating cover; rated 600V.

What the Morris 90990 Connects

The Morris 90990 adapts a 350 MCM aluminum or copper conductor to a 250 MCM solid pin. Its offset solid pin design is intended for this conductor-to-pin size transition.

Where an Offset Solid Pin Terminal Is Used

This connector is used to land aluminum or copper conductors in breakers, switches, panelboards, and lug terminals.

Barrel, Markings, and Insulating Cover

The barrel is aluminum with tin plating and is pre-filled with oxide inhibitor. Die index and crimp marks are provided on the barrel, and the connector is supplied with an EPDM insulating cover.

• Rated voltage: 600V
• Color code: Brown

Installation Guidance

Strip the conductor, insert it fully into the barrel, and crimp using the marked die. Slide the EPDM cover over the completed connection.

Before You Order

Confirm the model number and quantity required before ordering.
