Morris 90985 Offset Solid Pin Terminal, 2/0 AWG Wire / 1 AWG Pin

Product Overview

The Morris 90985 is an offset solid pin terminal connector for terminating a 2/0 AWG aluminum or copper conductor to a 1 AWG solid pin.

Its tin-plated aluminum barrel is pre-filled with oxide inhibitor. The terminal is rated 600 volts and is supplied with an EPDM insulating cover.

Key Features

• Offset solid pin design
• For 2/0 AWG aluminum or copper conductor and 1 AWG solid pin
• Tin-plated aluminum barrel pre-filled with oxide inhibitor
• Barrel has die index and crimp marks
• Supplied with EPDM insulating cover
• 600 V rating

What the Morris 90985 Terminal Connects

The Morris 90985 adapts a 2/0 AWG conductor to a smaller 1 AWG solid equipment pin. Its stated applications include landing aluminum or copper conductors in breakers, switches, panelboards and lug terminals.

Conductor and Pin Compatibility

This model is specified for a 2/0 AWG aluminum or copper conductor and a 1 AWG solid pin. The connector is rated 600 volts.

Barrel, Crimping and Insulating Cover

The tin-plated aluminum barrel is pre-filled with oxide inhibitor and has die index and crimp marks. For installation, strip the conductor, insert it fully into the barrel, and crimp using the marked die. Slide the supplied EPDM cover over the completed connection.

Before You Order

Confirm the model number and quantity required before ordering.
