Morris 90982 Straight Solid Pin Terminal, 500 MCM Wire / 350 MCM Pin

Product Overview

The Morris 90982 is a straight solid pin terminal connector that terminates a 500 MCM conductor into a 350 MCM solid pin.

It has a tin-plated aluminum barrel pre-filled with oxide inhibitor and ships with an EPDM insulating cover. Rated 600V.

Key Features

• Straight solid pin design for terminating 500 MCM wire to a 350 MCM pin
• All-aluminum barrel with tin plating for use with aluminum or copper conductors
• Barrel pre-filled with oxide inhibitor
• Die index and crimp marks on the barrel for crimp placement
• Supplied with an EPDM insulating cover
• Voltage rating: 600V

What this terminal does

The Morris 90982 adapts a 500 MCM conductor to a 350 MCM solid equipment pin. It is intended for landing conductors where a pin-style termination is required.

• Adapts 500 MCM conductor to a 350 MCM solid pin
• Intended for use when a pin termination is required for equipment connections

Materials and conductor compatibility

The terminal is aluminum with a tin-plated barrel finish. The product description indicates the tin plating supports use with both aluminum and copper conductors.

• Barrel material: aluminum, tin-plated
• Conductor compatibility: aluminum or copper conductors (500 MCM) per product description

Installation and crimp guidance

Strip the conductor, insert it fully into the barrel, and crimp at the marked die/crimp location. After crimping, slide the supplied EPDM insulating cover over the completed connection.

• Use the die index and crimp marks on the barrel for correct crimp placement
• Barrel ships pre-filled with oxide inhibitor
• Finish with the supplied EPDM insulating cover

Electrical rating

The terminal is rated for 600 volts; use this rating when assessing suitability for your circuit or equipment.

• Voltage rating: 600V

Before You Order

Verify the required conductor and pin sizes (500 MCM conductor to 350 MCM pin) before ordering.

• Ensure system voltage does not exceed 600V
• Confirm the terminal fits the intended equipment pin and that appropriate crimp tooling will be used
