Morris 90976 Straight Solid Pin Terminal, 3/0 AWG Wire / 1/0 AWG Pin

Product Overview

The Morris 90976 is a straight solid pin terminal connector for terminating a 3/0 AWG aluminum or copper conductor in a 1/0 AWG solid pin.

Its tin-plated aluminum barrel is pre-filled with oxide inhibitor and marked with a die index and crimp marks. An EPDM insulating cover is supplied.

Key Features

• Terminates 3/0 AWG aluminum or copper conductor to a 1/0 AWG solid pin
• Tin-plated aluminum barrel pre-filled with oxide inhibitor
• Barrel has die index and crimp marks
• Supplied with EPDM insulating cover
• Rated 600V

Conductor and Pin Configuration

The Morris 90976 adapts a 3/0 AWG conductor to a 1/0 AWG solid pin. It is specified for aluminum or copper conductors and has a straight solid-pin design.

• Conductor size: 3/0 AWG
• Pin size: 1/0 AWG
• Conductor material: aluminum or copper

Barrel and Insulating Cover

The connector has a tin-plated aluminum barrel pre-filled with oxide inhibitor. Die index and crimp marks are provided on the barrel, and an EPDM insulating cover is supplied.

• Barrel material: tin-plated aluminum
• Oxide inhibitor: pre-filled in barrel
• Insulating cover: EPDM

Applications and Installation

This terminal is used to land aluminum or copper conductors in breakers, switches, panelboards, and lug terminals where a larger conductor is adapted to a smaller equipment pin.

For the described installation, strip the conductor, insert it fully into the barrel, and crimp using the marked die. Slide the EPDM cover over the completed connection.

Before You Order

Confirm that the 3/0 AWG conductor size and 1/0 AWG pin size match your application.
