Morris 90971 Straight Solid Pin Terminal, 4 AWG Wire / 4 AWG Pin

Product Overview

The Morris 90971 is a straight solid pin terminal connector for terminating a 4 AWG aluminum or copper conductor to a 4 AWG solid pin. It is rated 600 volts.

The aluminum barrel is tin-plated and pre-filled with oxide inhibitor. The terminal is supplied with an EPDM insulating cover.

Key Features

• Straight solid pin design with 4 AWG wire and pin sizes
• Tin-plated aluminum barrel for aluminum or copper conductors
• Barrel pre-filled with oxide inhibitor
• Die index and crimp marks on the barrel
• Supplied with an EPDM insulating cover
• 600V rating

What the Morris 90971 Terminal Is Used For

The Morris 90971 adapts a 4 AWG conductor to a 4 AWG solid pin. Its stated applications include landing aluminum or copper conductors in breakers, switches, panelboards and lug terminals.

Conductor Compatibility and Barrel Features

The terminal has an aluminum barrel with tin plating and is specified for aluminum or copper conductors. The barrel is pre-filled with oxide inhibitor and has die index and crimp marks.

• The supplied EPDM cover fits over the completed connection.
• The terminal is rated 600 volts.

Installation Overview

To install, strip the conductor, insert it fully into the barrel and crimp using the marked die. Slide the EPDM cover over the completed connection.

Before You Order

Confirm that Morris catalog number 90971 and its 4 AWG wire and pin sizes match the intended connection.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 90971 Straight Solid Pin Terminal, 4 AWG Wire / 4 AWG Pin. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
