Morris 90970 Straight Solid Pin Terminal, 6 AWG Wire / 4 AWG Pin

Product Overview

The Morris 90970 is a straight solid pin terminal connector that terminates a 6 AWG aluminum or copper conductor into a 4 AWG solid pin.

The terminal has a tin‑plated aluminum barrel pre‑filled with oxide inhibitor and includes an EPDM insulating cover; it is rated 600 V.

Key Features

• Straight solid pin design for use with 4 AWG equipment pins
• All‑aluminum barrel with tin plating for use with aluminum and copper conductors
• Barrel pre‑filled with oxide inhibitor
• Die index and crimp marks on the barrel
• Supplied with EPDM insulating cover
• 600 V rating

What this terminal does

The Morris 90970 provides a straight solid pin termination to adapt a 6 AWG conductor for connection to a 4 AWG solid equipment pin. Typical landing points include breaker, switch, panelboard, and lug terminals where a solid pin is used.

Conductor and pin compatibility

This part is specified for a 6 AWG wire and a 4 AWG solid pin. The barrel is tin‑plated aluminum and is intended for use with aluminum or copper conductors.

• Wire size: 6 AWG
• Pin size: 4 AWG
• Conductor types: Aluminum or Copper

Installation and crimp guidance

Strip the conductor, insert it fully into the barrel, and crimp at the die index/crimp marks. After crimping, slide the supplied EPDM insulating cover over the completed connection.

• Follow the die index and crimp marks on the barrel for crimp placement
• Ensure full conductor insertion before crimping
• Use a crimp tool and die appropriate for the terminal and conductor (tooling not included)

Materials, insulation and electrical rating

The terminal is all‑aluminum with tin plating. The barrel ships pre‑filled with oxide inhibitor and an EPDM insulating cover is supplied. The product is rated 600 V.

• Material: Aluminum, tin‑plated
• Barrel: pre‑filled with oxide inhibitor
• Insulation: EPDM cover supplied
• Voltage rating: 600 V

Before You Order

Verify that you need a terminal for terminating a 6 AWG conductor onto a 4 AWG solid pin and that a 600 V rating and EPDM cover are suitable for your application.

• Confirm conductor material (Al or Cu) is compatible with a tin‑plated aluminum barrel
• Ensure you have a crimp tool and die appropriate for the terminal
