Morris 90566 Copper Mechanical Lug, 1/0-14 AWG

Product Overview

The Morris 90566 is a one-piece copper mechanical lug for terminating copper conductors from 1/0 through 14 AWG. It has a straight tang, a 7/16-inch stud hole, and a 1/4-inch hex steel screw.

This lug is rated 600V and is specified for copper wire only. Its listed applications include connections to a stud, bus, or equipment pad in panelboards, switchgear, and grounding terminations.

Key Features

• One-piece copper construction with a straight tang
• Accepts 1/0–14 AWG copper conductors only
• 7/16-inch stud hole and 1/4-inch hex steel screw
• 600V rating

Conductor Range and Material

The Morris 90566 accepts copper conductors from 1/0 through 14 AWG and is specified for copper wire only. Its 600V rating is listed for this mechanical lug.

Lug Configuration and Applications

The 90566 has a one-piece copper body, straight tang, 7/16-inch stud hole, and 1/4-inch hex steel screw. It is listed for terminating conductors to a stud, bus, or equipment pad in panelboards, switchgear, and grounding terminations.

Installation

The stated installation method is to strip the conductor, insert it into the barrel, and tighten the 1/4-inch hex screw to the UL 480 torque for the wire size.

Before You Order

Confirm that the conductor is copper and falls within the 1/0–14 AWG range, and that the 7/16-inch stud hole suits the intended connection.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 90566 Copper Mechanical Lug, 1/0-14 AWG. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
