Morris 89737 L6-15R Locking Receptacle, 15A 250V
Description
Product Overview
The Morris 89737 is a NEMA L6-15R locking (twist-lock) receptacle rated 15A at 250V for panel- or box-mounted use.
It features a nylon/polycarbonate housing, solid one-piece brass contacts set in deep pockets, heavy-duty brass terminal screws, a grounding screw, and a clear terminal chamber for visual inspection.
Key Features
- NEMA configuration: L6-15R (2-pole, 3-wire)
- Rated 15A, 250V
- Nylon/polycarbonate housing resistant to impact, abrasion, sunlight, and chemicals (per product description)
- Solid one-piece brass power contacts set in deep pockets
- Heavy-duty brass combo-head terminal screws and included grounding screw
- Clear terminal chamber for visual inspection; grooved housing for grip
What this receptacle does
The Morris 89737 is a locking (twist-lock) female receptacle with NEMA L6-15R configuration that provides a secure connection for 250V circuits requiring a 2-pole, 3-wire arrangement. It is intended for panel- or box-mounted installations.
- Provides a locking connection for compatible L6-15 plugs
- Specified for 15A, 250V circuits
Construction and materials
The housing is molded from nylon/polycarbonate. Contacts are solid one-piece brass set in deep pockets. The unit includes heavy-duty brass combo-head terminal screws and a grounding screw, and a clear terminal chamber for visual inspection.
- Nylon/polycarbonate housing
- Solid one-piece brass contacts
- Heavy-duty brass terminal screws and included grounding screw
- Clear terminal chamber for visual inspection
Typical applications
The product description lists use as a panel- or box-mounted L6-15R outlet for generators, equipment, and industrial power. The locking configuration is used where a twist-lock receptacle is required.
- Panel or box-mounted L6-15R outlet
- Generator and equipment power connections where an L6-15R is specified
Installation and wiring
Mount the receptacle into a suitably sized electrical box or panel opening. Terminate the line, neutral, and ground conductors on the provided brass terminal screws. A grounding screw is included with the unit.
- Panel- or box-mounted installation
- Terminate conductors on brass terminal screws
- Use the included grounding screw for equipment grounding
Technical specifications
Key electrical and configuration details for the Morris 89737 are listed below.
- NEMA configuration: L6-15R (locking receptacle)
- Amperage: 15 A
- Voltage: 250 V
- Poles/Wires: 2-pole, 3-wire
- Configuration: Receptacle (female)
- Housing material: Nylon/Polycarbonate; Contacts: Brass
- Includes grounding screw and clear terminal chamber
Before You Order
Verify the model number and that an L6-15R (NEMA) locking receptacle with 15A/250V ratings matches the mating plug, circuit, and mounting opening.
- Ensure compatibility with the mating L6-15 plug and circuit amperage/voltage
- Confirm the panel or box opening is suitable for a panel-mounted locking receptacle
Ordering from Lumera Electric
Check the purchasing options shown on the Lumera Electric product page for Morris 89737 L6-15R Locking Receptacle, 15A 250V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
Specifics
| Brand | Morris |
|---|---|
| SKU | 89737 |
| Type | Locking Receptacle |
| NEMA Configuration | L6-15R |
| Ampere Rating | 15A |
| Voltage | 250V |
| Poles / Wires | 2-Pole, 3-Wire |
| Configuration | Receptacle (Female) |
| Material | Nylon/Polycarbonate housing; Brass contacts |
