Morris 89736 L5-15R Locking Receptacle, 15A 125V

(No Ratings)
SKU: 89736
Price: $22.55
Free shipping on orders over $1,500

Description

Product Overview

The Morris 89736 is a NEMA L5-15R locking receptacle rated 15A at 125V (2-pole, 3-wire) for panel- or box-mounted use.

It has a nylon/polycarbonate housing, solid one-piece brass contacts set in deep pockets, heavy-duty brass terminal screws, a clear terminal chamber for terminal inspection, a grounding screw, and a grooved housing for grip.

Key Features

  • NEMA configuration: L5-15R (locking receptacle, female)
  • Electrical rating: 15A, 125V, 2-pole 3-wire
  • Nylon/polycarbonate housing
  • Solid one-piece brass contacts set in deep pockets
  • Heavy-duty brass combo-head terminal screws and grounding screw
  • Clear terminal chamber for visual inspection
  • Grooved housing for enhanced grip

Function and typical uses

The Morris 89736 is a panel- or box-mounted NEMA L5-15R locking receptacle for 15A, 125V circuits where a twist-lock outlet is required.

  • Panel- or box-mounted locking outlet
  • Used where a NEMA L5-15R receptacle is required

Construction and materials

The housing is made from a nylon/polycarbonate blend. Power and grounding contacts are solid one-piece brass and are set in deep pockets. The unit includes a clear terminal chamber.

  • Nylon/polycarbonate housing
  • Solid one-piece brass contacts
  • Clear terminal chamber

Electrical rating and wiring

Rated 15 amps at 125 volts, configured as 2-pole, 3-wire (NEMA L5-15R). Line, neutral (where applicable), and ground are terminated on the provided brass terminal screws.

  • Rating: 15A, 125V
  • Configuration: 2-pole, 3-wire (L5-15R)
  • Terminations on brass combo-head terminal screws
  • Includes grounding screw

Mounting and basic installation notes

The receptacle is intended for panel or box mounting and is installed into a compatible enclosure. Conductors are landed on the terminal screws and the clear terminal chamber allows visual inspection of the connections.

  • Panel- or box-mounted installation
  • Land conductors on the provided terminal screws

Identification and ordering

Identify the product by model/catalog number 89736 and NEMA configuration L5-15R.

  • Model/Catalog No.: 89736
  • NEMA: L5-15R (locking receptacle)

Before You Order

Confirm model number 89736 and NEMA configuration L5-15R match your requirements.

  • Check compatibility with the mating plug and enclosure cutout

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 89736 L5-15R Locking Receptacle, 15A 125V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.

Specifics

BrandMorris
SKU89736
NEMA ConfigurationL5-15R
Ampere Rating15A
Voltage125V
Poles / Wires2-Pole 3-Wire
Type / ConfigurationLocking Receptacle (female)
Housing MaterialNylon/Polycarbonate
ContactsSolid one-piece brass, set in deep pockets
Terminal ScrewsHeavy-duty brass combo-head
FeaturesClear terminal chamber, grounding screw, grooved housing
