Morris 89733 L5-20P Locking Plug, 20A 125V

(No Ratings)
SKU: 89733
Price: $20.81
Free shipping on orders over $1,500

Description

Product Overview

The Morris 89733 is a male NEMA L5-20P locking plug rated for 20A and 125V. Its configuration is 2-pole, 3-wire for compatible cord and equipment connections.

The plug has a nylon/polycarbonate housing, one-piece brass contacts, a clear terminal chamber, and a cord strain relief with rubber grommet.

Key Features

  • NEMA L5-20P male configuration, rated 20A and 125V
  • 2-pole, 3-wire design
  • Nylon/polycarbonate construction described as resistant to impact, abrasion, sunlight, and chemicals
  • One-piece brass contacts set in deep pockets
  • Grooved housing for grip and a clear terminal chamber for visual inspection
  • Brass combo-head terminal screws, cord strain relief, rubber grommet, and grounding screw

NEMA L5-20P Configuration and Rating

The Morris 89733 is a 20A, 125V NEMA L5-20P locking plug. It is a male, 2-pole, 3-wire device; confirm that the connection being made calls for this configuration.

  • NEMA configuration: L5-20P
  • Rating: 20A, 125V
  • Configuration: Male, 2-pole, 3-wire

Housing, Contacts, and Terminals

The housing is made of nylon/polycarbonate and has a grooved exterior. The catalog description identifies resistance to impact, abrasion, sunlight, and chemicals; it does not specify an environmental rating.

One-piece brass contacts are set in deep pockets. Brass combo-head terminal screws and a clear terminal chamber support conductor termination and visual inspection. The plug also includes a grounding screw, cord strain relief, and rubber grommet.

Use for Compatible Cord and Equipment Connections

This plug is described for 20A, 125V NEMA L5-20P locking power connections on cords and equipment in commercial and industrial settings. The installation description specifies connections for line, neutral, and ground conductors at the brass terminal screws, followed by assembly of the housing with the strain relief.

Before You Order

Confirm that the NEMA L5-20P configuration and 20A, 125V rating match the intended connection.

  • Confirm the model number and quantity required before ordering.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 89733 L5-20P Locking Plug, 20A 125V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.

Specifics

BrandMorris
Catalog Number89733
Product TypeLocking plug
NEMA ConfigurationL5-20P
Ampere Rating20A
Rated Voltage125V
Poles and wires2-pole, 3-wire
ConfigurationMale
Housing MaterialNylon/polycarbonate
Contact MaterialBrass
