Morris 89618 6-20P Straight-Blade Plug, 20A 250V
Description
Product Overview
The Morris 89618 is a NEMA 6-20P straight‑blade (male) plug rated 20A at 250V for 2‑pole, 3‑wire power connections.
It features a rugged nylon/polycarbonate housing, solid one‑piece brass contacts, heavy‑duty terminal screws, a clear terminal chamber for inspection, and integrated cord strain relief with rubber grommet.
Key Features
- NEMA 6-20P configuration (6-20P), 20A, 250V, 2‑pole 3‑wire, male plug
- Rugged nylon/polycarbonate housing resists impact, abrasion, sunlight, and chemicals
- All contacts are solid one‑piece brass; heavy‑duty power contacts set in deep pockets
- Heavy‑duty brass combo‑head terminal screws and clear terminal chamber for visual inspection
- Grooved housing for enhanced grip, included grounding screw, cord strain relief and rubber grommet
What this plug is for
Answer: The Morris 89618 is intended for making 20A, 250V NEMA 6‑20P straight‑blade (male) connections on cords and compatible equipment. It is a 2‑pole, 3‑wire configuration suitable where a NEMA 6‑20P receptacle is required.
- NEMA configuration: 6-20P (straight‑blade plug)
- Rating: 20A, 250V
- Poles/Wires: 2‑pole, 3‑wire (includes grounding provision)
Construction and durability
Answer: The housing and contact design prioritize mechanical robustness and reliable conductivity.
- Housing: rugged nylon/polycarbonate to resist impact, abrasion, sunlight, and chemicals
- Contacts: solid one‑piece brass for conductivity and reduced heat rise
- Grip: grooved housing for improved handling
- Inspection and sealing: clear terminal chamber for visual inspection, rubber grommet and cord strain relief to protect the connection
Installation summary
Answer: The 89618 is field‑wiring friendly and assembled on a stranded or solid cord by terminating conductors under the provided brass terminal screws and securing the housing with the integrated strain relief.
- Strip the cord conductors to the appropriate length and terminate line, neutral, and ground under the heavy‑duty combo‑head terminal screws
- Use the clear terminal chamber to verify connections before final assembly
- Assemble the housing and engage the cord strain relief and rubber grommet to secure and seal the cord
Technical specifications
Answer: Key electrical and material specifications for the Morris 89618 are listed below.
- Brand: Morris
- Catalog number/SKU: 89618
- Type: Straight‑blade plug (male)
- NEMA configuration: 6‑20P
- Amperage: 20A
- Voltage: 250V
- Poles/Wires: 2‑pole, 3‑wire
- Material: Nylon/Polycarbonate housing; brass contacts
- Includes: grounding screw, rubber grommet, cord strain relief
Before You Order
Confirm the model number and NEMA configuration (6‑20P) match the receptacle and cord requirements for your application before ordering.
- Verify the 20A, 250V rating is appropriate for the equipment or circuit.
- Confirm cable conductor size and strand count are compatible with the plug's terminal screws.
Ordering from Lumera Electric
Check the purchasing options shown on the Lumera Electric product page for Morris 89618 6-20P Straight-Blade Plug, 20A 250V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
Specifics
| Brand | Morris |
|---|---|
| SKU | 89618; '89618 |
| Type | Straight‑Blade Plug (male) |
| NEMA Configuration | 6‑20P |
| Ampere Rating | 20A |
| Voltage | 250V |
| Poles / Wires | 2‑Pole, 3‑Wire |
| Material | Nylon/Polycarbonate housing; brass contacts |
| Included Items | Grounding screw, rubber grommet, cord strain relief |
