Morris 20460 L15-20P Recessed Locking Plug, 20A 250V
Description
Product Overview
The Morris 20460 is a male NEMA L15-20P recessed locking plug rated 20A and 250V, with a 3-pole, 4-wire configuration.
Its flange is designed for flush mounting in an equipment panel or enclosure. The grooved housing, brass contacts, and clear terminal chamber are built into the plug's design.
Key Features
- NEMA L15-20P configuration; 20A, 250V; 3-pole, 4-wire
- Flanged design for flush or recessed panel and enclosure mounting
- Nylon/polycarbonate construction with grooved housing
- One-piece brass contacts set in deep pockets
- Heavy-duty brass combination-head terminal screws and clear terminal chamber
Electrical Configuration and Locking Connection
The Morris 20460 is a male NEMA L15-20P locking plug rated 20A and 250V. Its configuration is 3-pole, 4-wire, making the L15-20P designation the key identifier to check when matching this plug to the intended connection.
Flush Panel and Enclosure Mounting
The flanged body is designed for flush or recessed mounting in a panel or enclosure. The product is described for use as a locking power point on equipment panels, gensets, and enclosures.
- The flange is intended for panel or enclosure mounting.
- Installation involves preparing a panel opening, mounting the flange, and connecting conductors to the brass terminals.
Housing, Contacts, and Terminals
The housing is made from nylon and polycarbonate and has a grooved surface for grip. The product description states that the housing resists impact, abrasion, sunlight, and chemicals.
One-piece brass contacts are set in deep pockets. Heavy-duty brass combination-head terminal screws provide the conductor termination points, and the clear terminal chamber allows visual inspection of the terminals.
- Includes a grounding screw.
Before You Order
Confirm that the NEMA L15-20P configuration, 20A rating, 250V rating, and flush-mounting design match your intended installation.
Ordering from Lumera Electric
Check the purchasing options shown on the Lumera Electric product page for Morris 20460 L15-20P Recessed Locking Plug, 20A 250V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
Specifics
| Brand | Morris |
|---|---|
| Catalog Number | 20460 |
| Product Type | Recessed locking plug |
| NEMA Configuration | L15-20P |
| Rating | 20A, 250V |
| Poles and wires | 3-pole, 4-wire |
| Configuration | Male; flush/recessed |
| Mounting Type | Flanged for panel or enclosure |
| Housing Material | Nylon/polycarbonate |
| Contact Material | Brass |
