Morris 20455 L8-20R Locking Receptacle, 20A 480V

(No Ratings)
SKU: 20455
Price: $11.79
Free shipping on orders over $1,500

Description

Product Overview

The Morris 20455 is a NEMA L8-20R locking receptacle rated 20A at 480V (2-pole, 3-wire) for panel- or box-mounted industrial power connections.

Constructed of impact- and chemical-resistant nylon/polycarbonate with solid one-piece brass power contacts set in deep pockets and a clear terminal chamber for visual inspection.

Key Features

  • NEMA L8-20R configuration (L8-20R) — 20A, 480V, 2-pole 3-wire locking receptacle
  • Rugged nylon/polycarbonate housing resists impact, abrasion, sunlight, and chemicals
  • All contacts are solid one-piece brass for conductivity and reduced heat rise
  • Heavy-duty power contacts set in deep pockets with brass combo-head terminal screws
  • Clear terminal chamber for visual inspection and includes grounding screw
  • Grooved housing for enhanced grip during plugging/unplugging

What this receptacle does

The Morris 20455 provides a secure locking outlet in the NEMA L8-20R configuration for 20A, 480V, 2-pole 3-wire circuits. It is intended for use where a twist-lock connection is required to prevent accidental disconnection.

  • Provides a female locking connection compatible with L8-20P plugs
  • Used to deliver 20A at 480V to compatible equipment and generators

Typical applications

This receptacle is used as a panel- or box-mounted locking outlet for generators, industrial equipment, and other installations that require a 20A 480V L8-20R connection.

  • Panel- or box-mounted power outlet for equipment and generator connections
  • Industrial and commercial installations requiring twist-lock receptacles

Construction and materials

The housing is molded from a nylon/polycarbonate blend chosen for impact, abrasion, sunlight, and chemical resistance. Power contacts are solid one-piece brass set in deep pockets to support conductivity and reduce heat rise.

  • Nylon/polycarbonate housing
  • Solid one-piece brass contacts and heavy-duty brass terminal screws
  • Clear terminal chamber for visual inspection
  • Includes grounding screw

Installation summary

Mount the receptacle in a suitable box or panel and land the line, neutral, and ground conductors on the provided brass terminal screws. The clear terminal chamber allows visual confirmation of terminated conductors.

  • Designed for box or panel mounting
  • Terminate line, neutral, and ground on brass combo-head screws
  • Confirm NEMA L8-20R compatibility with mating plug and circuit

Key specifications

Reference the following technical details to confirm this SKU meets your selection criteria.

  • NEMA configuration: L8-20R
  • Amperage: 20A
  • Voltage: 480V
  • Poles/Wires: 2-pole, 3-wire
  • Material: Nylon/Polycarbonate housing; brass contacts

Before You Order

Confirm the model number and quantity required before ordering. Verify that NEMA L8-20R (20A, 480V, 2-pole 3-wire) matches your mating plug and circuit requirements.

  • Confirm compatibility with the mating L8-20P plug and supply voltage
  • Ensure proper box or panel cutout and access for a clear terminal chamber
  • Consult a qualified electrician to verify wire sizing and installation per local code

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Morris 20455 L8-20R Locking Receptacle, 20A 480V. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.

Specifics

BrandMorris
SKU20455
TypeLocking Receptacle
NEMA ConfigurationL8-20R
Ampere Rating20A
Voltage480V
Poles / Wires2-Pole 3-Wire
ConfigurationReceptacle (Female)
MaterialNylon/Polycarbonate housing; Brass contacts
Included ItemsGrounding screw; clear terminal chamber
