Leviton 21254-H Pin & Sleeve Device
Description
Product Overview
The Leviton 21254-H is a hospital‑grade pin & sleeve receptacle configured as a brown 4‑in‑1 device: 2‑pole plus grounding, 3‑wire grounding. It is rated 20A, 125V and supplied as a single unit (SKU 21254-H).
Designed and manufactured by Leviton, this device is intended for residential, commercial, and industrial electrical applications where a durable, grounded pin & sleeve receptacle is required.
Key Features
- Hospital‑grade receptacle construction
- 4‑in‑1 pin & sleeve configuration: 2P + G, 3‑wire grounding
- Electrical rating: 20 amps, 125 volts
- Color: Brown
- Single SKU: 21254-H (UPC 07847783080)
Function and intended use
The Leviton 21254-H is a pin & sleeve receptacle intended to provide a grounded connection in systems that use pin & sleeve interconnects. Its hospital‑grade designation indicates it is built to meet higher mechanical and quality standards appropriate for demanding environments such as healthcare facilities, commercial spaces, or industrial installations requiring durable wiring devices.
- Pin & sleeve configuration for robust mating with compatible plugs
- Hospital‑grade construction for higher reliability and retention
Electrical rating and wiring
This device is rated 20A at 125V and wired as a 2‑pole plus grounding, 3‑wire grounding receptacle. Use only where the system voltage and current match this rating and where a compatible pin & sleeve plug is specified.
- Ampacity: 20 A
- Voltage: 125 V
- Wiring: 2 pole + ground (3‑wire grounding)
Physical attributes and identification
Confirm model and physical details to ensure compatibility with your installation. The 21254‑H is finished in brown and supplied as a single EA unit.
- Manufacturer: Leviton
- Model / Item #: 21254‑H
- Color: Brown
- UPC: 07847783080
- Weight: 6.0 lb (unit)
Ordering and use considerations
Verify the model number, wiring requirements, and quantity required before placing an order. Confirm that a 20A/125V pin & sleeve receptacle in a 2P+G 3‑wire grounding configuration is appropriate for the intended circuit and mating plug.
- Single SKU: 21254‑H
- Unit of measure: Each (EA)
Before You Order
Confirm the model number and quantity required before ordering. Ensure the 20A/125V 2P+G wiring, hospital‑grade construction, and brown finish match your project specifications and the mating plug type.
- Verify compatibility with the circuit voltage and ampacity.
- Confirm you have the correct mating pin & sleeve plug for a 4‑in‑1 2P+G receptacle.
- If unsure, consult your electrician or project specifications before purchase.
Ordering from Lumera Electric
Check the purchasing options shown on the Lumera Electric product page for Leviton 21254-H Pin & Sleeve Device. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
Specifics
| Brand | Leviton |
|---|---|
| SKU | 21254-H |
| Type | Pin & Sleeve Device |
| Configuration | 2P + G (3‑wire grounding), 4‑in‑1 |
| Rating | 20A, 125V |
| Grade | Hospital Grade |
| Finish | Brown |
| UPC | 07847783080 |
| Weight | 6.0 lb |
| Unit of Measure | EA |
