Intermatic 480 VAC 60Hz Outdoor Mechanical Time Switch T1475BR

Product Overview

The Intermatic T1475BR is a 24-hour mechanical time switch with Skip-a-Day functionality for scheduled control of electrical loads at 480 VAC, 60Hz.

It has a 4-SPST switch configuration, 1-hour switching intervals, and is supplied in an outdoor metal enclosure.

Key Features

• Voltage: 480 VAC, Frequency: 60Hz
• 24-hour mechanical timer with Skip-a-Day
• 4-SPST switch configuration (four single-pole single-throw outputs)
• 1-hour switching interval
• Outdoor metal enclosure
• Manufacturer SKU/MPN: T1475BR; UPC: 078275179097
• Unit weight: 3.892 lb; master pack quantity: 6

What this timer does

The T1475BR provides scheduled on/off control via a 24-hour mechanical dial with Skip-a-Day capability. It is intended to control electrical loads where a 1-hour resolution schedule is acceptable.

The mechanical trippers operate at 1-hour intervals to create daily or multi-day on/off schedules without electronic programming.

• 24-hour mechanical dial with Skip-a-Day
• 1-hour switching increments

Voltage and frequency

This model is specified for 480 VAC operation at 60Hz. Confirm the supply voltage and frequency at the installation site before selecting this unit.

• Rated voltage: 480 VAC
• Rated frequency: 60Hz

Switches and control outputs

The T1475BR provides four single-pole single-throw (4-SPST) contacts. Each SPST contact can be used to switch a separate circuit per the application's requirements.

Verify load ratings and wiring methods with a qualified professional to ensure compatibility.

• Switch configuration: 4-SPST (four SPST outputs)

Enclosure and location rating

The unit is supplied in an outdoor metal enclosure and is indicated for outdoor location installations. Confirm local code and environmental requirements for mounting and wiring.

Plan for appropriate conduit, gaskets, and sealing as required by the authority having jurisdiction.

• Enclosure: Outdoor metal enclosure
• Location rating: Outdoor

Weights and packaging

Use unit weight and packaging quantities to plan shipping and stocking for contractor or bulk orders.

• Unit weight: 3.892 lb
• Master pack quantity: 6 (master pack weight: 23.352 lb)
• Pallet quantity: 144 (pallet weight: 560.448 lb)

Before You Order

Confirm the model number (T1475BR), supply voltage (480 VAC), and that the 4-SPST outputs meet your load control requirements. Electrical products should be selected and installed by a qualified professional in accordance with local codes.

• Verify site supply is 480 VAC, 60Hz
• Confirm 4-SPST outputs meet load control needs
• Confirm enclosure and mounting meet local environmental and code requirements
