EnVision LED-RST-4FT-3M80W-4CCT-BMS – 2' Strip w/ Microwave Sensor

Product Overview

The EnVision LED-RST-4FT-3M80W-4CCT-BMS is a 2-foot commercial LED strip with field-selectable wattage (80/65/50W) and 4 CCT options (3000K–5000K).

The fixture operates on 120–277V, offers 0–10V dimming, is rated for damp locations, and is UL and DLC listed.

Key Features

• Field-selectable wattage: 80 / 65 / 50 W
• Selectable lumen output: 10,400 / 8,450 / 6,500 lm corresponding to wattage
• Field-selectable CCT: 3000K, 3500K, 4000K, 5000K (4 CCT)
• Universal input voltage: 120–277V
• 0–10V dimming
• 130° beam angle
• CRI > 80
• Damp location rated; white finish
• Certifications: UL and DLC listed; 5-year warranty
• Packaged quantity: 6 per box

What this fixture does

The LED-RST-4FT-3M80W-4CCT-BMS is a 2-foot LED strip intended for general commercial and utility interior spaces. It provides selectable wattage and color temperature so one SKU can serve multiple requirements.

• Field-selectable wattage (80 / 65 / 50 W)
• Selectable CCT (3000K, 3500K, 4000K, 5000K)
• Includes a microwave sensor option (BMS) for presence detection

Light output and selectable performance

Lumen output varies with the selected wattage, allowing specification flexibility without reordering different SKUs.

• 80 W → 10,400 lumens
• 65 W → 8,450 lumens
• 50 W → 6,500 lumens
• 130° beam angle

Controls and dimming

The fixture supports 0–10V dimming for analog continuous control and is available with an integrated microwave sensor option for occupancy sensing.

• 0–10V analog dimming compatibility
• Integrated microwave sensor (BMS) option — configuration set at install

Mounting and installation notes

Basic installation requires confirming mounting method and making the field selections for wattage and CCT prior to final mounting.

• Set wattage and CCT switches on the fixture before final installation
• Confirm fixture length and mounting method match the run layout
• Verify the specified location is appropriate for a damp-rated fixture

Key technical specifications

Quick reference for electrical, optical and compliance details.

• Input voltage: 120–277V
• Dimming: 0–10V
• CRI: >80
• Finish: White
• Rating: Damp Location
• Certifications: UL and DLC listed; 5-year warranty
• Packaged quantity: 6 per box
• UPC: 810143710328

Before You Order

Confirm model number, quantity, and that the mounting method and location are appropriate for a 2' damp-rated strip. Set desired wattage and CCT on the fixture before final mounting.

• Verify the location is suitable for a damp-rated fixture.
• If pursuing utility rebates, confirm DLC qualification with your program’s current QPL.
• Confirm control wiring requirements for 0–10V dimming and sensor configuration.
