EnVision LED-EDL-4-10W-5CCT-WH-12V – 4" Low Voltage Premium Downlight

Product Overview

The EnVision LED-EDL-4-10W-5CCT-WH-12V is a 4" low-voltage retrofit downlight that delivers 10W and 600 lumens with five selectable color temperatures for specification flexibility.

The fixture includes a GU5.3 (2-pin MR16) socket and mounts into most 4" compatible recessed housings using tension clip springs; it is ETL listed and carries a 5-year limited warranty.

Key Features

• Wattage: 10W; Output: 600 lumens
• 5‑CCT selectable: 2700K / 3000K / 3500K / 4000K / 5000K (Select-n-Switch)
• 12V low-voltage with GU5.3 (MR16) 2‑pin socket for retrofit compatibility
• Dimming: Triac/ELV (manufacturer notes 12V Triac dimmable down to 5% with compatible transformer or dimmer)
• Beam angle: 100°; Frosted acrylic, non‑yellowing lens; White finish
• Die-cast aluminum housing and trim; fixture removable from below ceiling for service
• Wet-location rated; operating temperature -40° to 114° F; average life (L70) 50,000 hours
• ETL listed for USA & Canada; FCC compliant; IC rated; ASTM-E283 air‑tight; 5‑year limited warranty

What this fixture is for

Direct answer: The LED-EDL-4-10W-5CCT-WH-12V is a 4" low-voltage recessed downlight intended for retrofitting MR16 low-voltage housings.

Manufacturer-listed applications include general recessed lighting, residential & multifamily, office and meeting rooms, education, healthcare, retail, and hospitality.

• Includes GU5.3 (2-pin MR16) socket for retrofit compatibility
• Designed for use in spaces where a compact 4" downlight with selectable CCT is desired

Light output & color options

Direct answer: The fixture produces 600 lumens at 10W and offers five selectable color temperatures: 2700K, 3000K, 3500K, 4000K, and 5000K.

Optical components include a frosted acrylic lens (non-yellowing) and a 100° beam angle for wide general illumination.

• Lumen output: 600 lm
• Selectable CCT: 2700K / 3000K / 3500K / 4000K / 5000K
• CRI: >90 with R9 >50 (manufacturer specification)

Low-voltage retrofit & dimming compatibility

Direct answer: This model is built for 12V low-voltage systems and installs into MR16 low-voltage housings using the GU5.3 connector and tension clip springs.

Manufacturer documentation states the product is Triac dimmable down to 5% when used with a compatible magnetic or electronic transformer and provides a list of tested dimmers.

• Voltage: 12V low-voltage
• Connector: GU5.3 (MR16) 2‑pin socket
• Dimming: Triac/ELV capable; 12V Triac dimmable to 5% with compatible transformer/dimmer (use tested dimmers or confirm compatibility)
• Built-in 2.5 kV surge protector and described as flicker-free by manufacturer

Mounting and physical details

Direct answer: The downlight mounts with tension clip springs to fit most 4" housings and can be removed from below the ceiling for service or replacement.

The fixture has a die-cast aluminum housing and trim for heat dissipation and a frosted acrylic lens for stable optical performance.

• Trim finish: White smooth
• Beam angle: 100°; lens: frosted acrylic (non-yellowing)
• Operating temperature: -40° to 114° F
• Average life (L70): 50,000 hours (manufacturer rating)

Listings and warranty

Direct answer: The LED-EDL-4-10W-5CCT-WH-12V is ETL listed for the U.S. and Canada and carries a 5-year limited warranty.

Additional manufacturer-stated compliance includes FCC CFR 47 Part 15, IC rating, and ASTM-E283 air-tight designation.

• ETL listed (USA & Canada)
• FCC CFR 47, Part 15 compliant
• IC rated; ASTM-E283 air‑tight
• 5-year limited warranty

Before You Order

Confirm you need a 12V GU5.3 (MR16) retrofit downlight and that your existing housing and transformer are compatible before ordering.

• Verify the housing accepts 4" tension-clip retrofit downlights and that a GU5.3 socket or wiring is available.
• If dimming is required, confirm the transformer is dimmable (magnetic or electronic) and check compatibility with tested dimmers or consult Lumera/EnVision.
