EMCOD MLE300-24DC Triac Dimmable Electronic LED Driver 300W 24VDC NO

Product Overview

Constant-voltage electronic LED driver for 24V DC LED tape and linear low-voltage fixtures.

Delivers up to 300W at 24V DC with triac phase dimming and built-in overload, short-circuit, and thermal protection.

Key Features

• Constant-voltage PWM output for 24V LED loads
• Triac phase dimming compatible with forward and reverse phase dimmers (manufacturer listing)
• Supports up to 300W maximum load
• 5% minimum load requirement (manufacturer listing)
• Protections: overload, short-circuit, thermal
• Operating temperature range: -40°C to +60°C
• Manufacturer listing notes flicker-free dimming support and good line/load regulation

What this driver does

The EMCOD MLE300-24DC is a constant-voltage electronic LED driver that provides a regulated 24V DC PWM output for 24V LED tape and linear low-voltage fixtures.

• Typical listed use cases: LED tape lighting, cabinet lighting, linear LED fixtures, residential and commercial low-voltage LED lighting.

Power and output specifications

This model supplies 24V DC output and is listed with a 300W maximum load. It is described as a PWM constant-voltage source for 24V LED products.

• Output voltage: 24V DC
• Maximum load: 300W
• Minimum load requirement: 5% (manufacturer listing)

Dimming compatibility and behavior

The product listing specifies triac phase dimming compatibility and notes support for both forward and reverse phase dimmers. Dimming is implemented using PWM according to the manufacturer listing.

• Triac phase dimming — manufacturer listing indicates compatibility with forward and reverse phase dimmers
• Manufacturer listing indicates flicker-free dimming support

Environment, protection and reliability

Manufacturer listing indicates multiple protective features and a wide operating temperature range for use in indoor and controlled-environment installations.

• Protections: overload, short-circuit, thermal
• Operating temperature range: -40°C to +60°C

Physical dimensions and packaging

Verify physical fit and ordering quantities before installation.

• Listed dimensions: Height = 10.94, Width = 4.25, Depth = 1.77
• Case quantity (listed): 10

Before You Order

Confirm model number, required quantity, and that the connected 24V LED load and dimmer type match the listed specifications.

• Ensure total connected LED load does not exceed 300W and meets the 5% minimum load requirement.
• Confirm your dimmer is a compatible forward or reverse phase triac type if using phase dimming.
• Check the listed dimensions and case quantity to confirm fit and ordering multiples.
