EMCOD MLE200-24DC Triac Dimmable Electronic LED Driver 200W 24VDC NO

Product Overview

The EMCOD MLE200-24DC is a triac-dimmable electronic LED driver for LED tape lighting. It provides 24V DC constant-voltage PWM output and has a maximum load of 200W.

Item number MLE200-24DC belongs to the EMCOD MLE Mini-LED Electronic family. Features include forward- and reverse-phase dimming, a 5% minimum load, and overload, short-circuit and thermal protection.

Key Features

• 24V DC constant-voltage PWM output with a maximum load of 200W
• Triac phase dimming for forward- and reverse-phase dimmers
• 5% minimum load
• Overload, short-circuit and thermal protection
• Operating temperature range of -40°C to +60°C

24V DC Output and Maximum Load

The MLE200-24DC provides constant-voltage 24V DC output using PWM and has a maximum load of 200W.

Triac Dimming and Protection

This driver is designed for triac phase dimming with forward- and reverse-phase dimmers. Its minimum load is 5%. Protection features include overload, short-circuit and thermal protection; flicker-free dimming support is also specified.

• Excellent line and load regulation

Lighting Applications

Applications include LED tape lighting, cabinet lighting, linear LED fixtures, and residential and commercial low-voltage LED lighting.

Dimensions and Product Identification

Dimensions are H = 10.3, W = 4.06 and D = 1.77; units are not specified. The item number is MLE200-24DC, and the class designation is NO.

Before You Order

Check that the item number is MLE200-24DC.
