EMCOD ML60S24DC Indoor Outdoor Magnetic DC Driver 60W 24VDC Class 2

Product Overview

The EMCOD ML60S24DC is a magnetic hard‑wire DC driver designed for low‑voltage lighting. It provides up to 60W output at 24V DC and carries a Class 2 designation.

Engineered for indoor or outdoor use, the unit features a manual reset primary circuit breaker, secondary protection for DC output, polyester resin encapsulation and a two‑section bobbin for primary‑to‑secondary insulation.

Key Features

• 60W maximum load, 24V DC output (SKU: ML60S24DC)
• Class 2 power supply
• Dimmable magnetic hard‑wire design
• Primary manual reset circuit breaker and secondary protection
• Two‑section bobbin for primary/secondary isolation; polyester resin encapsulation for quiet operation
• Outdoor‑rated enclosure: NEMA 3R or IP24
• Compact dimensions: H 8.13" × W 3.93" × D 1.59"

What this driver does

The ML60S24DC converts mains input to a regulated 24V DC output for low‑voltage lighting loads. It is a magnetic hard‑wire driver intended to supply LED, halogen or xenon low‑voltage fixtures that accept a 24V DC source.

Electrical output and load

Answer: 24V DC output with a 60W maximum load and Class 2 designation.

• Output voltage: 24V DC
• Maximum load: 60W (do not exceed rated wattage)
• Class designation: Class 2

Protection and enclosure

Answer: The unit includes primary and secondary protective features and is suitable for indoor or outdoor installations where a NEMA 3R/IP24 enclosure is acceptable.

• Primary: manually reset circuit breaker (standard)
• Secondary: protection standard for DC products
• Insulation: two‑section bobbin provides separation between primary and secondary
• Encapsulation: polyester resin for reduced audible noise
• Enclosure rating: NEMA 3R or IP24

Physical size and mounting notes

Answer: Compact rectangular driver sized for in‑line mounting in lighting circuits.

• Dimensions: Height 8.13 in, Width 3.93 in, Depth 1.59 in

Typical applications

Answer: The ML60S24DC is intended for low‑voltage lighting systems indoors or outdoors.

• Low‑voltage LED fixtures
• Halogen and xenon low‑voltage fixtures
• Indoor and outdoor lighting circuits that accept a 24V DC Class 2 supply

Before You Order

Confirm the model number and quantity required before ordering. This page describes the single SKU ML60S24DC (60W, 24V DC).

• Verify that your fixtures accept a 24V DC Class 2 supply and that combined fixture wattage does not exceed 60W.
• Ensure NEMA 3R / IP24 enclosure rating meets site environmental requirements.
• Consult a qualified electrician for wiring and local code compliance.
