EMCOD ML60S12DC Indoor Outdoor Magnetic DC Driver 60W 12VDC Class 2

Product Overview

The EMCOD ML60S12DC is a magnetic hard‑wire DC driver designed to supply low‑voltage LED, halogen or xenon fixtures. It delivers up to 60W at 12V DC and carries a Class 2 designation.

Built for indoor or outdoor use, the unit features primary manual reset protection, secondary protection for the DC output, encapsulated construction for quiet operation and a two‑section bobbin that insulates primary and secondary windings.

Key Features

• 60W maximum load with 12V DC output
• Class 2 power supply
• Dimmable magnetic hard‑wire design
• Primary manually reset circuit breaker and standard secondary protection
• Two‑section bobbin for primary/secondary insulation
• Polyester resin encapsulation for quiet operation
• Outdoor enclosure rated NEMA 3R / IP24

What this driver does

The ML60S12DC is a magnetic DC driver intended to convert mains power to low‑voltage DC for lighting fixtures. It is specified for use with low‑voltage LED fixtures and is also listed for halogen and xenon fixtures.

• Application examples: low‑voltage LED, halogen, xenon fixtures
• Series / family: ML/EM Magnetic Driver

Electrical output and limits

This unit supplies a 12V DC output and supports a maximum load of 60 watts. It is designated Class 2, which defines the driver’s limited power output characteristics.

• Output voltage: 12V DC
• Maximum load: 60W
• Class designation: Class 2

Protections and dimming

The ML60S12DC is a magnetic hard‑wire driver that is dimmable and includes built‑in protective features to improve safety and serviceability.

• Dimmable magnetic design
• Primary protection: manually reset circuit breaker (standard)
• Secondary protection: provided for DC output

Enclosure and environmental suitability

The driver is packaged in an outdoor‑rated enclosure and may be used indoors or outdoors where a NEMA 3R / IP24 enclosure is acceptable.

• Outdoor enclosure rating: NEMA 3R / IP24
• Encapsulation: polyester resin for quieter operation

Size and physical details

Confirm physical dimensions and SKU when planning installation or mounting.

• Dimensions: Height = 8.13 in, Width = 3.93 in, Depth = 1.59 in
• SKU / Item Number: ML60S12DC
• UPC: 810064710902
• Case quantity: 12

Before You Order

Confirm the model number and quantity required before ordering. Verify that 12V DC and a 60W maximum supply meet the requirements of the fixture(s) you intend to power.

• This page covers the single SKU ML60S12DC; confirm compatibility with your fixtures and dimming method.
• Check local codes and installation requirements for outdoor or hard‑wired power supplies.
