EMCOD ML50S24AC Indoor Outdoor Magnetic AC Driver 50W 24VAC C2

Product Overview

The EMCOD ML50S24AC is a magnetic hard‑wire AC driver designed for 24VAC low‑voltage lighting circuits. It delivers up to 50W output and carries a C2 class designation.

Engineered for indoor or outdoor use, the unit is encapsulated in polyester resin for quiet operation and is supplied with a manual reset primary circuit breaker and a boost tap to compensate voltage drop on long runs.

Key Features

• 50W maximum load at 24VAC output
• Magnetic, dimmable hard‑wire power supply
• Boost tap on AC models to compensate for long‑run voltage drop
• Primary manually reset circuit breaker included
• Two‑section bobbin for primary/secondary insulation
• Encapsulated in polyester resin for quiet operation
• Outdoor enclosure rated NEMA 3R / IP24

What this driver does

The ML50S24AC is a magnetic AC driver that supplies low‑voltage AC power for low‑voltage lighting fixtures such as halogen, xenon, and AC landscape or architectural lighting circuits.

It is a hard‑wire, dimmable supply intended to convert and regulate line power to a 24VAC output suitable for compatible fixtures and transformers.

• Designed specifically for 24VAC lighting circuits
• Suitable for halogen, xenon, and other low‑voltage AC fixtures where a magnetic driver is required

Electrical output and load

This unit provides a 24VAC output with a maximum load capacity of 50 watts and carries a C2 class designation.

AC versions of the ML series include a boost tap to compensate for voltage drop on long cable runs, helping maintain lamp performance at the far end of a circuit.

• Output: 24V AC
• Max load: 50W
• Class designation: C2
• Includes boost tap on AC units

Installation and environmental suitability

The ML50S24AC is rated for indoor or outdoor installation and is supplied in an enclosure rated NEMA 3R / IP24, providing protection suitable for many covered outdoor locations.

It is a hard‑wire device; installers should follow applicable electrical codes and use appropriate enclosures and wiring methods for the installation environment.

• Enclosure rating: NEMA 3R / IP24 (outdoor capable)
• Hard‑wire installation — requires qualified electrician for wiring and compliance

Construction features and safety components

The driver uses a two‑section bobbin to maintain insulation between primary and secondary windings and is encapsulated with polyester resin to reduce audible noise.

A primary manually reset circuit breaker is standard on the unit to provide overload protection at the input.

• Two‑section bobbin separates primary and secondary
• Polyester resin encapsulation for quiet operation
• Primary manual reset circuit breaker provided

Dimensions and identification

Confirm physical size and SKU when planning mounting and enclosure space. The ML50S24AC is identified by SKU ML50S24AC and UPC 810064710858.

Dimensions are listed as height = 7, width = 2.11, depth = 1.54 (units as provided by manufacturer documentation).

• SKU / Item Number: ML50S24AC
• UPC: 810064710858
• Dimensions: H = 7, W = 2.11, D = 1.54

Before You Order

Confirm the model number, output voltage, and wattage required for your fixtures before ordering. Verify mounting space using the listed dimensions.

• Confirm ML50S24AC is the correct SKU for your 24VAC, 50W requirement
• Specify required quantity and consult a qualified electrician for hard‑wire installation

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for EMCOD ML50S24AC Indoor Outdoor Magnetic AC Driver 50W 24VAC C2. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
