EMCOD ML40S24DC Indoor Outdoor Magnetic DC Driver 40W 24VDC Class 2

Product Overview

The EMCOD ML40S24DC is a magnetic hard‑wire DC driver that provides up to 40W of 24V DC power for low‑voltage lighting circuits. It is designed for indoor and outdoor use with a NEMA 3R / IP24 rated enclosure.

The unit includes primary manual reset circuit breaker, secondary protection for the DC side, a two‑section bobbin for primary/secondary insulation, and polyester resin encapsulation for quiet operation.

Key Features

• 40W maximum load at 24V DC output (SKU: ML40S24DC)
• Class 2 designation for low‑voltage lighting circuits
• Dimmable magnetic hard‑wire power supply
• Primary manual reset circuit breaker and secondary DC protection
• Two‑section bobbin insulation and polyester resin encapsulation
• Outdoor enclosure rated NEMA 3R / IP24

What this driver does

The EMCOD ML40S24DC is a magnetic DC driver designed to step down and supply a regulated 24V DC output to low‑voltage lighting fixtures. It is a hard‑wire unit intended to be integrated into lighting circuits where a 24V DC Class 2 source is required.

Typical applications

Use the ML40S24DC for 24V low‑voltage LED fixtures and other low‑voltage lighting loads compatible with a magnetic DC supply. The manufacturer lists use with low‑voltage LED, halogen and xenon fixtures and for both indoor and outdoor lighting circuits.

• Low‑voltage LED fixtures
• Halogen and xenon low‑voltage fixtures
• Indoor and outdoor lighting circuits where a 24V DC Class 2 supply is required

Electrical output and protections

This SKU delivers 24V DC with a maximum load of 40W and carries a Class 2 designation. The unit is dimmable as a magnetic driver and incorporates a primary manual reset circuit breaker and secondary protection on the DC side for added safety.

• Output: 24V DC
• Maximum load: 40W
• Class designation: Class 2
• Primary manual reset circuit breaker (standard)
• Secondary protection for DC products (standard)

Size, construction and enclosure

The ML40S24DC is encapsulated in polyester resin for quiet operation and uses a two‑section bobbin to provide insulation between primary and secondary windings. The listed physical dimensions and enclosure rating help determine mounting and environmental suitability.

• Dimensions (listed): H = 7, W = 2.11, D = 1.54
• Two‑section bobbin for primary/secondary insulation
• Encapsulated with polyester resin
• Outdoor enclosure rating: NEMA 3R / IP24

Before you order

Confirm that the ML40S24DC (SKU ML40S24DC) matches the voltage and wattage needs of your fixtures and that a Class 2 24V DC magnetic driver is appropriate for the installation. Verify physical space and environmental rating for the intended mounting location.

• Confirm model number and quantity required before ordering.
• Verify your fixtures are compatible with a 24V DC magnetic driver and with dimming via magnetic control.
• Check mounting space against the listed dimensions.

Before You Order

Confirm the model number ML40S24DC and that 24V DC at up to 40W meets your fixture and circuit requirements. Ensure the NEMA 3R / IP24 enclosure rating and listed dimensions suit your installation location.

• Confirm model number and quantity required before ordering.
• Verify compatibility with your fixtures (24V DC, magnetic dimming where applicable).
• Check physical mounting space against the listed dimensions.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for EMCOD ML40S24DC Indoor Outdoor Magnetic DC Driver 40W 24VDC Class 2. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
