CHPSURGE - Eaton 2-Pole 240VAC Circuit Breaker Surge Protective Device 18000A 10kAIC BR Frame Plug-On

Product Overview

The CHPSURGE is an Eaton 2‑pole 240VAC circuit breaker surge protective device designed for BR frame plug‑on distribution panels.

It carries an 18,000A surge rating and a 10 kA interrupting rating (10kAIC). Intended for new installations where a plug‑on BR frame breaker is required.

Key Features

• Eaton part number: CHPSURGE
• 2‑pole, 240 VAC surge protective circuit breaker
• 18,000A surge rating
• 10 kA interrupting rating (10kAIC)
• BR frame, plug‑on mounting

Function and primary purpose

The CHPSURGE is a combination circuit breaker and surge protective device built for 2‑pole, 240 VAC applications. It provides overcurrent protection as a plug‑on BR frame breaker while incorporating surge mitigation capability with an 18,000A surge rating.

• Combines circuit protection and surge suppression in a single BR frame plug‑on unit
• Suitable for branch circuits in 240 VAC distribution systems where a 2‑pole breaker is required

Electrical ratings and interrupting capacity

Key electrical characteristics supplied for the CHPSURGE are its 18,000A surge rating and a 10 kA interrupting rating (10kAIC). Use these figures to compare the device against the expected surge exposure and available fault current at the point of installation.

• Rated surge capacity: 18,000A
• Interrupting capacity: 10 kAIC (10,000 A interrupting rating)
• Nominal system voltage: 240 VAC (2‑pole)

Physical frame and panel mounting

The unit is described as a BR frame plug‑on breaker. That indicates it is intended to mount directly into compatible BR frame distribution panels using a plug‑on connection.

• Frame: BR
• Mounting: plug‑on style for BR frames

Ordering and verification

Confirm the Eaton model number and the electrical and mechanical requirements for your panel before ordering. This product page covers one Eaton SKU: CHPSURGE.

• Manufacturer: Eaton
• Part number/SKU: CHPSURGE
• Condition: New — request a quote for pricing and availability

Before You Order

Confirm the CHPSURGE model number and that a BR frame plug‑on breaker is compatible with your panel and system fault current. Request a quote for pricing and availability.

• Verify panel type and physical space for a BR frame plug‑on breaker.
• Confirm your system voltage and required interrupting rating meet or exceed 240 VAC and 10 kA respectively.
• If you need additional technical details or installation guidance, provide the panel model and site fault‑current information when requesting a quote.

Ordering from Lumera Electric
