CHF230 - Cutler Hammer 30A 120/240V Two-Pole Thermal Magnetic Circuit Breaker Type CHF 10kAIC

Product Overview

The CHF230 is an Eaton (Cutler Hammer) Type CHF two‑pole thermal magnetic circuit breaker rated 30 amps for 120/240V service with a 10 kAIC interrupting rating.

This listing is for one new CHF230 circuit breaker (part number CHF230). Request a quote for pricing and availability.

Key Features

• Two‑pole thermal magnetic protection for simultaneous interruption of both poles
• 30 A continuous ampere rating for 120/240V branch circuits
• 10 kAIC interrupting rating
• Manufacturer: Eaton (Cutler Hammer) — Part number CHF230

Function and intended use

The CHF230 is a two‑pole thermal magnetic circuit breaker designed to provide overcurrent protection and switching for 120/240V single‑phase branch circuits. As a two‑pole device, it opens both line conductors simultaneously to protect multi‑wire branch circuits and loads requiring simultaneous disconnection.

• Protects against overloads (thermal trip) and short circuits (magnetic trip)
• Used in panelboards and load centers where a Type CHF breaker is specified

Electrical ratings and performance

Key electrical specifications identify the CHF230’s rated operating parameters for system planning and compatibility.

• Ampere rating: 30 A
• Voltage rating: 120/240 V
• Interrupting rating: 10 kAIC (10,000 A interrupting capacity)

Compatibility and application notes

Use the CHF230 where a Cutler Hammer Type CHF two‑pole breaker is specified. Confirm panelboard compatibility and that the panel accepts the CHF footprint and trip style.

• Intended for use in Eaton/Cutler Hammer compatible panels and load centers designed for Type CHF breakers
• Verify physical fit, bus connection type, and trip coordination in the target panel before installation

Ordering and pre-purchase checks

This product page describes the Eaton CHF230 by part number. Confirming model and quantity is recommended before requesting pricing or placing an order.

• Confirm the exact part number (CHF230) and required quantity before ordering
• Request a quote for pricing and availability

Before You Order

Confirm the model number and quantity required before ordering. Verify panel compatibility, mounting type, and any required local code or jobsite specifications.

• Confirm part number: CHF230
• Verify the breaker fits the intended panelboard (type CHF footprint and bus connection)
• If unsure about compatibility or application, consult the panel manufacturer’s documentation or an electrician
