Diode LED Channel Component, Lens, Black, 96 in (DI-CPCHC-BL96)

Product Overview

The Diode LED DI-CPCHC-BL96 is a 96-inch aluminum LED channel extrusion with a black finish designed to house and finish low-voltage LED tape light runs.

Aluminum construction provides a thermal path that helps draw heat away from LED tape; the extrusion accepts matching lenses, end caps, and mounting clips from the same channel family for a finished installation.

Key Features

• 96 in (8 ft) aluminum extrusion for linear LED tape installations
• Black finish for discreet integration in millwork and architectural applications
• Acts as a heat sink to help manage LED tape temperature and preserve output
• Cut-to-length extrusion that can be trimmed to fit custom cabinetry and display runs
• Designed to pair with Diode LED lenses, end caps, and mounting clips in the same series

What this channel does

The DI-CPCHC-BL96 provides a rigid aluminum housing sized for linear LED tape to create a clean finished edge and to protect the tape from mechanical contact and dust.

Because the body is aluminum, it also provides a thermal path that helps draw heat away from the LED tape, supporting stable output and preserving run length where thermal management matters.

• Houses low-voltage LED tape (verify tape width against channel opening before installation)
• Provides a finished architectural transition when used with lenses and end caps

Recommended applications

This 96 in channel is intended for long linear runs in built environments where a discreet, finished linear light is required.

Common uses are under-cabinet and above-cabinet accent lighting, cove and perimeter lighting, toe-kick illumination, and shelf or display edge lighting.

• Under-cabinet, above-cabinet, and cove lighting
• Shelf, display, and millwork edge lighting
• Toe-kick and perimeter accent illumination

Installation and handling notes

The extrusion is cut-to-length to fit custom cabinetry and casework. Because this SKU is supplied as a full 96 in piece, plan for handling and delivery of a long rigid extrusion.

Support the extrusion at its mounting clip points to keep a long run straight and avoid sagging.

• Trim to required length for the installation; verify cut and finish methods are appropriate for aluminum
• Support at clip/mounting points during and after installation to maintain a straight run

Compatibility and accessories

The channel is designed to pair with matching lenses, end caps, and mounting clips from the same Diode LED channel series for a finished assembly.

Confirm the LED tape width and profile before ordering to ensure it fits the channel opening.

• Pairs with Diode LED lenses, end caps, and mounting clips in the same channel family
• Verify tape width compatibility prior to installation

Key specifications

Reference the following verified product details for planning and specification.

• Brand: Diode LED
• Model / SKU: DI-CPCHC-BL96
• Product type: LED Channel Component
• Material: Aluminum
• Finish: Black
• Length: 96 in

Before You Order

Confirm the model number and quantity required before ordering. Verify LED tape width and any site access or handling constraints for a 96 in extrusion.

• Confirm tape width against the channel opening
• Plan for handling and support of a 96 in rigid extrusion
• Specify matching lenses, end caps, and mounting clips if a finished assembly is required
