Diode LED Channel Bundle, 45°, 96 in, Black, Black Lens, 2 open end cap, 2 closed end cap, 4 mounting clips (DI-CPCHB-45-BL-96B)

Product Overview

The Diode LED DI-CPCHB-45-BL-96B is a 45° aluminum LED channel bundle supplied as a ready-to-mount 96 in section for mounting low-voltage LED tape light.

The aluminum extrusion serves as the channel body; the bundle includes a black lens, two open end caps, two closed end caps, and four mounting clips.

Key Features

• 45° corner profile for directed edge and corner illumination
• Aluminum extrusion construction
• 96 in length — supplied as a cut-to-length linear section
• Black finish with matching black lens
• Bundle includes: 2 open end caps, 2 closed end caps, 4 mounting clips

What this channel does

The DI-CPCHB-45-BL-96B provides a finished housing for low-voltage LED tape and presents the light at a 45° angle from the channel face.

• 45° profile positions light toward edges and inside corners.
• Black finish and black lens reduce the visibility of the channel in many interiors.
• Supplied as a single 96 in section for linear runs.

Recommended applications

Typical uses are in cabinet, cove, and millwork installations where a 45° aiming angle is suitable.

• Under-cabinet and above-cabinet accent lighting
• Cove, toe-kick, and perimeter lighting
• Shelf, display, and millwork edge lighting
• Corner and inside-angle linear runs

Mounting and handling notes

Install the extrusion with the supplied mounting clips. Verify LED tape width against the channel opening before installation and plan for handling a 96 in extrusion during delivery and placement.

• Support the extrusion at clip locations to keep the section straight.
• Confirm tape width compatibility with the channel opening prior to installation.
• The aluminum extrusion can be cut to length to fit custom dimensions.

Key specifications

Use these product details to confirm fit and selection for your project.

• Brand: Diode LED
• Model / SKU: DI-CPCHB-45-BL-96B
• Product type: LED Channel Bundle
• Profile: 45° Corner
• Material: Aluminum
• Finish: Black
• Length: 96 in
• Bundle contents: black lens, 2 open end caps, 2 closed end caps, 4 mounting clips

Before You Order

Verify LED tape width compatibility with the channel opening and plan for delivery and installation of a 96 in extrusion.

• Confirm LED tape width fits the channel opening.
• Plan handling for a 96 in section during delivery and installation.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Diode LED Channel Bundle, 45°, 96 in, Black, Black Lens, 2 open end cap, 2 closed end cap, 4 mounting clips (DI-CPCHB-45-BL-96B). For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
