CRSA-SIGEND-3PIN Corsa 3pin DMX Signal Terminator

Product Overview

3‑pin DMX signal end cap for use with Corsa DMX fixtures. Contains a 120 Ω resistor between the DMX + and - conductors to provide line termination.

Finished in anodized aluminum and sold individually under SKU CRSA-SIGEND-3PIN.

Key Features

• 120 Ω termination resistor between DMX + and -
• Intended for Corsa fixtures that accept a 3‑pin DMX terminator
• Anodized aluminum finish
• Sold individually (SKU CRSA-SIGEND-3PIN)

What this part does

This is a 3‑pin DMX signal end cap that installs on the last fixture or the end of a DMX run. It places a 120 Ω resistor between the DMX + and - conductors to provide termination for the data line.

• Provides a 120 Ω termination between DMX + and - to complete line termination.

Compatibility

The CRSA-SIGEND-3PIN is intended for use with Corsa DMX fixtures that accept a 3‑pin signal end cap. Verify that the fixture uses a 3‑pin DMX connector before purchase.

• Designed for fixtures in the Corsa product family that require a 3‑pin DMX terminator.
• Not intended as a direct replacement for 5‑pin DMX connectors unless the fixture specifies 3‑pin compatibility.

Finish and packaging

Finished in anodized aluminum and sold individually. Listed under part number/SKU CRSA-SIGEND-3PIN.

• Finish: Anodized aluminum
• Sold as: Each
• SKU / Part Number: CRSA-SIGEND-3PIN

Before You Order

Verify that your fixture uses a 3‑pin DMX connector and requires a termination at the end of the DMX run.

• Confirm fixture connector type (3‑pin vs 5‑pin) before purchase.
