AML-DEC-DALI-5CH DALI DT6 & DT8 5-Channel 12-36VDC CV LED Decoder (5CH x 5A)

Product Overview

DALI-2 certified DT6 & DT8 5-channel constant-voltage (CV) LED decoder for use in DALI lighting control systems.

Accepts 12–36VDC input and provides five independently controlled CV outputs, each rated at 5 A. Green enclosure; sold as each (SKU AML-DEC-DALI-5CH).

Key Features

• DALI-2 certified supporting DT6 and DT8 control protocols
• Five independently addressable channels, each rated 5 A
• Works with 12–36VDC constant-voltage LED power sources
• Compact decoder for integration into DALI lighting control installations
• SKU: AML-DEC-DALI-5CH — sold individually

What this decoder does

The AML-DEC-DALI-5CH is a five-channel LED decoder designed to convert DALI control signals into constant-voltage outputs for LED loads. Each channel is independently addressable, enabling individual control of up to five separate LED circuits from a single decoder within a DALI lighting network.

• Converts DALI DT6/DT8 commands to CV LED outputs
• Supports independent control of five LED channels

Electrical input and output requirements

This decoder accepts a DC input voltage range of 12–36 VDC and provides five constant-voltage outputs. Each output channel is rated for up to 5 A, permitting straightforward sizing against LED strip or fixture loads.

• Input voltage: 12–36 VDC
• Output: 5 channels, constant-voltage
• Per-channel current rating: 5 A

DALI protocol and control compatibility

The unit is marked DALI-2 certified and supports DT6 and DT8 control modes. DT6 typically covers basic dimming control, while DT8 adds color and tunable white handling; the decoder is intended for use where DALI DT6/DT8 device behavior is required.

• DALI-2 certified (DT6 and DT8)
• Integrates into DALI lighting control systems for central or distributed control

Product identity and packaging

This item is sold individually under SKU AML-DEC-DALI-5CH. The decoder is supplied in a green-colored enclosure and is categorized as a controls product for lighting automation.

• Brand: American Lighting
• SKU / Part Number: AML-DEC-DALI-5CH
• Sold as: Each
• CCT / Color (enclosure): Green

Before You Order

Confirm the model number and quantity required before ordering. Verify that your LED fixtures and DC power supply match the decoder's 12–36 VDC input range and that per-channel currents do not exceed 5 A.

• Confirm compatibility with your DALI controller and whether DT6 or DT8 behavior meets your application needs.
• Ensure each LED channel's load current is within the 5 A per-channel rating.
• Check wiring, connector types, and installation requirements with your integrator or installer prior to purchase.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for AML-DEC-DALI-5CH DALI DT6 & DT8 5-Channel 12-36VDC CV LED Decoder (5CH x 5A). For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
