Utopia Lighting EB3 Wall EB3 Linear Wall Mount Fixture

Product Overview

The Utopia Lighting EB3 Wall is an LED linear wall-mount fixture for architectural interiors, offices and commercial spaces. Listed product-family ranges are 5–40W and 115–4,600 lumens, with 115 lm/W efficacy.

Ordering options describe individual- and continuous-row configurations, nominal 2-, 3- and 4-foot lengths, selectable color temperature, and mounting choices. The default SKU does not identify a specific configuration; confirm the required options when requesting a quote.

Key Features

• Utopia Lighting LED linear wall-mount fixture
• Product range: 5–40W and 115–4,600 lumens
• Selectable 3000K, 3500K or 4000K color temperature
• 120–277V input and 0–10V dimming
• Ordering options include individual- or continuous-row configurations

Output and selectable color temperature

The EB3 Wall is listed with a 5–40W range, 115–4,600 lumens and 115 lm/W efficacy. Ordering options identify selectable 3000K, 3500K or 4000K color temperature. The default SKU does not identify a specific configuration.

Voltage and dimming

The fixture is listed for 120–277V and 0–10V dimming.

Lengths and mounting configurations

Ordering options describe individual-mount and continuous-row-mount configurations, along with a custom option. Listed nominal lengths are 2, 3 and 4 feet. Mounting choices include T-bar ceiling, spackle flange (trimless) and flanged trim for drywall ceiling.

• Code 3S is described with adjustable 100%, 75% or 50% settings.
• Mounting kits are shipped separately.
• A sketch is required for field installation when ordering the custom configuration.

Listings and location rating

Listed designations are UL, CUL, damp location and ARRA.

Before You Order

Confirm the configuration, length, color temperature and mounting option when requesting a quote; the default SKU does not specify a selected configuration.

• Mounting kits are shipped separately.
• A sketch is required for field installation when ordering the custom configuration.
