Premium Lighting EDI-PAN14-15T50W-xxK G1 Backlit Panel G1 1x4 50W 125lm/W 6250lm, Sensor Base

Product Overview

The Premium Lighting EDI-PAN14-15T50W-xxK G1 is a 1x4 LED backlit panel with selectable wattage and color temperature settings.

Onboard switches allow selection of 15W, 20W, 30W, 40W or 50W and 3000K, 3500K, 4000K, 5000K, 5700K or 6500K. At 50W, the panel produces up to 6,250 lumens at 125 lm/W.

Key Features

• Five selectable wattage settings: 15W, 20W, 30W, 40W and 50W
• Six selectable CCT settings from 3000K to 6500K
• Maximum output of 6,250 lumens at 125 lm/W
• Sensor-ready base accepts plug-in occupancy or microwave sensors
• DLC product ID S-JF1M8R

Selectable Wattage and CCT

The EDI-PAN14-15T50W-xxK G1 offers five wattage settings and six color temperatures, selected with onboard switches at installation. The wattage options are 15W, 20W, 30W, 40W and 50W; the CCT options are 3000K, 3500K, 4000K, 5000K, 5700K and 6500K.

Light Output

At its maximum 50W setting, this 1x4 LED backlit panel produces up to 6,250 lumens, with a stated efficacy of 125 lm/W.

Sensor-Ready Base

The panel has a sensor-ready base that accepts plug-in occupancy or microwave sensors.

Applications and Ceiling Fit

Listed application settings include open offices, conference rooms, classrooms, libraries, medical suites and exam rooms. Confirm the grid size and ceiling type before ordering. A surface-mount frame kit is required for hard ceilings.

Before You Order

Confirm the grid size and ceiling type for the intended installation. A surface-mount frame kit is required on hard ceilings.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Premium Lighting EDI-PAN14-15T50W-xxK G1 Backlit Panel G1 1x4 50W 125lm/W 6250lm, Sensor Base. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
