Panasonic APS Atmosphere Air Pressure Sensing Switch with Electrical Cycle Timing Board

Product Overview

Panasonic APS is an inline duct fan in the Atmosphere Inline Fans family designed for residential and commercial ventilation where verified sound and airflow performance are part of the specification.

This SKU (APS) integrates an air pressure sensing switch with an electrical cycle timing board so the fan runs for a set period after activation, supporting applications such as remote-mounted bathroom exhaust and multi-room ventilation.

Key Features

• Air pressure sensing switch for activation based on duct/airflow conditions
• Integrated electrical timing board that runs the fan for a set period after activation
• Designed to Panasonic Atmosphere Inline Fans contractor and facility specifications
• Intended for remote-mounted bathroom exhaust, multi-room ventilation, and commercial ventilation installations

Function and intended use

The Panasonic APS combines an inline duct fan with an air pressure sensing switch and an electrical cycle timing board. It is intended to provide mechanically assisted ventilation where activation and delayed run-time are required, such as remote-mounted bathroom exhaust or multi-room ventilation schemes.

• Inline duct fan design for centralized or remote installations
• Pressure sensing switch triggers the fan based on airflow/pressure conditions
• Integrated timer provides a defined post-activation run period

Timing board and activation

The APS includes an electrical cycle timing board that runs the fan for a set period after activation. The timing function is integrated with the unit’s pressure sensing switch so the fan continues operating for the configured interval once triggered.

• Built-in timer runs fan for a set period after activation
• Activation is tied to the unit’s pressure sensing switch

Typical applications

The APS is suitable for installations that require verified ventilation performance and delayed shutdown. Common uses include remote-mounted bathroom exhaust fans, multi-room ventilation configurations, and select commercial ventilation applications where inline fans are specified.

• Remote-mounted bathroom exhaust
• Multi-room ventilation
• Commercial building ventilation where inline fans are specified

Mounting and duct connection considerations

Confirm the duct connection and mounting location suit the run and local code or project requirements. The APS is supplied as an inline unit; installation details such as duct size, mounting method, and local electrical requirements must be verified against the project plan.

• Verify duct connection compatibility and routing
• Confirm mounting location accommodates an inline fan and associated wiring
• Adhere to local codes and installer best practices for ventilation equipment

Identifiers

Use the model and UPC below for specification, ordering, and cross-referencing with project documentation.

• Model / SKU: APS
• UPC: 6 28507 70003 4
• Brand: Panasonic

Before You Order

Confirm the model number and quantity required before ordering. Verify duct size, mounting location, and electrical connection requirements for your installation.

• Confirm APS is the correct model for your duct size and ventilation scheme
• Verify mounting space for an inline unit and plan wiring for the integrated timer and switch
• Refer to project specifications or consult an installer for code compliance and compatibility
