Leviton 560MI5WLEV Pin & Sleeve Device

Product Overview

The Leviton 560MI5WLEV is a pin & sleeve device with a 60 amp mechanical interlock in a black finish. It is a genuine Leviton wiring device intended for residential, commercial, and industrial electrical applications.

Unit weight is 11.5 lb and the product is sold per each (EA). UPC: 07847725163.

Key Features

• 60A mechanical interlock
• Pin & sleeve type device from Leviton
• Black finish
• Packed and sold as individual unit (EA)
• UPC 07847725163

Function and purpose

The Leviton 560MI5WLEV is a pin & sleeve device built with a 60 amp mechanical interlock to provide a secure electrical connection where controlled mating and unmating of power is required. Mechanical interlocks are commonly used to ensure a safe sequence of operation during connection and disconnection.

• Device type: Pin & sleeve with mechanical interlock
• Interlock rating: 60A

Basic specifications

Key product identifiers and physical details for quick verification.

• Brand: Leviton
• Model / Item #: 560MI5WLEV
• UPC: 07847725163
• Unit of measure: EA
• Weight: 11.5 lb
• Color/finish: Black

Typical applications

This Leviton pin & sleeve device is suitable for residential, commercial, and industrial electrical installations where a 60A mechanical interlock is required to manage safe connections.

• Used where controlled plug/receptacle sequencing is needed
• Applies to wiring-device installations in commercial and industrial settings
• Also appropriate for certain residential installations requiring pin & sleeve connections

Compatibility and performance notes

Compatibility with receptacles, enclosures, or other system components is determined by matching the exact Leviton model and configuration. Performance ratings such as voltage, environment, temperature, and specific mounting or wiring requirements are not provided here; confirm these details against the equipment or plans before specifying.

• Confirm matching mating receptacle and mechanical-interlock components
• Refer to project electrical drawings or Leviton technical literature for application-specific ratings

Before You Order

Confirm the model number and quantity required before ordering. Verify mating receptacle, voltage, enclosure and installation requirements for your project — those details are not listed here.

• Confirm 560MI5WLEV is the exact Leviton model required for your installation
• Verify compatibility with existing pin & sleeve receptacles and any enclosure or wiring constraints
• Contact Lumera Electric or consult Leviton technical documentation for application-specific ratings and installation guidance

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Leviton 560MI5WLEV Pin & Sleeve Device. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
