Kuzco Vega LED Vanity Light VL10323

Product Overview

Integrated LED Kuzco Vega vanity light, model VL10323-WH in White. Produces 1360 total lumens at 3000K while drawing 16W (1108 delivered lumens).

Damp-location rated with ADA-compliant projection and ELV dimming capability (dimmer sold separately).

Key Features

• Integrated LED: 16W, 1360 total lumens; 1108 delivered lumens
• 3000K color temperature with 90 CRI
• ELV dimmer compatible (100–10%); dimmer not included
• ETL listed; damp-location rated; Title 24 JA8-2022 compliant
• Aluminum housing with white acrylic diffuser; wall-mount, down illumination
• LED life span: 50,000 hours

What this fixture is for

The Kuzco Vega VL10323-WH is an integrated LED vanity light with a 23‑inch profile and downward illumination. It is offered in a White finish and is intended for applications such as bathroom vanity lighting, mirror-flanking installations, or hallway accent lighting.

• Primary applications: bathroom vanities, powder rooms, hallway accents
• Illumination direction: down
• Mounting style: wall mount (all orientation)

Light output and color quality

This fixture is specified to produce 1360 total lumens at 3000K with a 90 CRI rating. Delivered lumen output through the diffuser is listed as 1108 lm.

• Color temperature: 3000K
• CRI: 90
• Total lumens: 1360 lm
• Delivered lumens: 1108 lm
• LED rated life: 50,000 hours

Dimming and controls

The VL10323-WH is compatible with ELV (electronic low-voltage) wall dimmers and is specified to dim between 100% and 10% with a compatible control. The dimmer is not included with the fixture.

• Dimming method: ELV dimmer (optional; not included)
• Dimming range: 100–10%
• Ensure any chosen dimmer is compatible with low-wattage LED loads

Dimensions and construction

Use the listed dimensions to verify fit and mounting location. The fixture has an aluminum body and a white acrylic diffuser for even light distribution.

• Primary dimension: 23 in
• Fixture dimensions: W 23" × H 1-3/8" × E 3-1/4"
• Canopy dimensions: W 4-3/4" × H 4-3/4" × E 3/8"
• Materials: Aluminum housing, white acrylic diffuser

Ratings, compliance, and finish

The VL10323-WH is ETL listed and carries a damp-location rating. It is indicated as meeting Title 24 JA8-2022 and has an ADA-compliant projection. Finish: White.

• Safety listing: ETL
• Environmental rating: Damp location
• Accessibility/code: ADA-compliant projection; Title 24 JA8-2022 compliant
• Finish: White
• Country of origin: China

Before You Order

Confirm the model number and finish before ordering; this page documents the White finish (VL10323-WH).

• Dimming requires a compatible ELV wall dimmer; dimmer is sold separately.
• Verify fixture and canopy dimensions for your mounting location.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Kuzco Vega LED Vanity Light VL10323. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
