Kuzco Pluto LED Wall Sconce WS47305

Product Overview

The Kuzco Pluto WS47305-CH is an integrated LED wall sconce finished in chrome. It consumes 6W and produces 400 lumens (320 lumens delivered) at 3000K, and is rated for dry interior locations.

This ETL-listed fixture offers 90 CRI color rendering, is compatible with ELV dimming, and is listed as Title 24 JA8-2022 compliant.

Key Features

• Integrated LED — 6W input, 400 lm (320 lm delivered)
• 3000K color temperature with 90 CRI
• ELV dimming compatible (100–10%; dimmer not included)
• Rated for dry interior locations
• ETL listed and JA8-2022 compliant
• Steel and glass construction with chrome finish

Function and light output

The WS47305-CH provides downward illumination from an integrated LED module that consumes 6 watts and produces 400 lumens (320 lumens delivered). Its 3000K color temperature offers warm white light appropriate for ambient and accent lighting; the 90 CRI is specified to support accurate color rendering.

• Input power: 6W
• Total lumen output: 400 lm (320 lm delivered)
• Color temperature: 3000K
• Color rendering index: 90

Dimming and controls

The fixture is compatible with ELV (electronic low-voltage) dimmers and is specified to dim from 100% down to 10% when used with a compatible ELV wall dimmer. The wall dimmer is not included.

• Dimming type: ELV
• Dimming range: 100–10%
• Dimmer sold separately — choose one compatible with the fixture and rated for its load

Dimensions and mounting

The Pluto WS47305-CH is compact and designed for wall mounting. Refer to the listed dimensions to confirm fit for your installation.

• Primary dimension: 5 in
• Fixture dimensions: D5" x E4-3/4"
• Canopy dimensions: D5" x E1/2"
• Mounting style: Wall mount, all orientation
• Illumination direction: Down

Recommended applications

This dry-location-rated sconce is intended for interior residential spaces where wall-mounted ambient or accent lighting is desired.

• Living rooms and bedrooms
• Entryways and hallways
• Dining and gathering spaces

Certifications and technical specifications

The WS47305-CH is ETL listed and indicated as JA8-2022 compliant. The integrated LED module is specified with a rated life of 50,000 hours. Materials are listed as steel and glass; the fixture is finished in chrome and manufactured in China.

• Certification: ETL listed
• Title 24: JA8-2022 compliant
• LED life span: 50,000 hours
• Material: Steel and glass
• Finish: Chrome
• Country of origin: China
• Input voltage: 120V

Before You Order

Confirm the SKU and finish required. If you plan to dim the fixture, select an ELV dimmer compatible with the fixture and rated for its load.

• Verify SKU: WS47305-CH for chrome (other finish available as WS47305-BG).
• Dimmer sold separately — choose an ELV dimmer compatible with a 6W LED load.
• Fixture is rated for dry interior locations only.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Kuzco Pluto LED Wall Sconce WS47305. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
