Kuzco Piazza LED Chandelier CH88224

Product Overview

The Kuzco Piazza CH88224-WH is a 24-inch, two-layer integrated LED chandelier in a white finish. The LED engine consumes 87W and produces 6500 lumens (3689 lm delivered) at 3000K with 90 CRI.

Intended for dry interior locations, the fixture is sloped-ceiling adaptable using 120" of field-adjustable wire. It is ETL listed and meets California Title 24 JA8-2022 high-efficacy requirements.

Key Features

• Integrated LED engine: 87W input — 6500 lm (engine), 3689 lm delivered
• Color: 3000K, 90 CRI
• Dimming: TRIAC/ELV to 10% or 0–10V control options (dimmers not included)
• Mounting: Field-adjustable 120" wire; minimum hang height 16"
• Construction: Aluminum and polymeric materials with frosted silicone diffuser
• Ratings: ETL listed; Title 24 JA8-2022 compliant; rated for dry locations

What this fixture does

The Piazza CH88224-WH is an integrated LED chandelier intended for residential interior use where an overhead statement fixture is desired. The LED engine consumes 87W and provides 6500 lumens (3689 lm delivered) of downward-directed light at 3000K, 90 CRI.

• Integrated light source — no lamp replacement for the LED engine specified.
• 3000K color temperature with 90 CRI.

Electrical requirements & dimming

The fixture is built for 120–277V input and supports dimming to 10% using either TRIAC/ELV controls or 0–10V systems. Dimmers are sold separately; choose controls compatible with the listed dimming method and the fixture’s electrical ratings.

• Input voltage: 120–277V
• Dimming range: 100–10%
• Dimming methods: TRIAC/ELV or 0–10V (control hardware not included)

Mounting, wire length and ceiling adaptability

The chandelier mounts suspended from field-adjustable wire and is adaptable to sloped ceilings when adjusted within the provided wire length.

• Field-adjustable wire length: 120"
• Minimum hang height: 16"
• Sloped-ceiling adaptable

Fixture and canopy dimensions

Confirm the fixture footprint and canopy dimensions to ensure appropriate scale and clearance in the intended space.

• Primary dimension: 24-inch, 2-layer
• Fixture: L 23-5/8" x W 23-5/8" x H 1-3/8"
• Canopy: L 8-1/2" x W 8-1/2" x H 2"

Ratings and compliance

The CH88224-WH is ETL listed, meets Title 24 JA8-2022 high-efficacy requirements, and is rated for dry interior locations.

• ETL listed
• Title 24 JA8-2022 compliant
• Location rating: Dry locations

Before You Order

Confirm the CH88224-WH model, fixture size, minimum hang height (16"), and 120" maximum wire length fit your location.

• Fixture is rated for dry interior locations only.
• Dimmers and any additional mounting hardware beyond the supplied canopy/wire are not included.
