Focus Industries IAL0310 Area Light

Product Overview

Focus Industries IAL0310NLBLT is a 10" Pagoda-series area light supplied as socket-only (no lamp) for line-voltage landscape and pathway illumination.

Constructed from spun 6061 aluminum with a Black Texture polyester powder-coat finish and listed with an IP54 rating.

Key Features

• Model: IAL0310NLBLT — Pagoda Series, 3-tier with 10" top hat
• Material: spun 6061 aluminum
• Finish: Black Texture polyester powder coat (BL T)
• Lamp platform: medium-base socket supplied — fixture ships No Lamp (lamp supplied by others)
• Top hat diameter: 10" (254 mm)
• Ingress protection: IP54 (manufacturer data)

Function and intended use

The IAL0310NLBLT is a decorative Pagoda-series area light intended for landscape and pathway illumination. It is supplied as a socket-only fixture (no lamp) for use with medium-base lamps selected by the installer.

• Typical applications: pathways, general landscape area lighting, and exterior accenting.
• Suitable for new installations, retrofits, and contractor stock when a medium-base, line-voltage fixture is required.

Light source and lamp compatibility

This SKU includes a medium-base (MB) socket and does not include a lamp. Installers should select a medium-base lamp compatible with their required line-voltage supply.

Manufacturer documentation shows the IAL series is offered for line-voltage wiring; verify the correct voltage and lamp selection for your project.

• Socket: medium-base (MB) supplied — lamp by others.
• Verify lamp wattage, type, and voltage compatibility before installation.

Dimensions and weight

IAL0310 indicates the 3-tier Pagoda configuration with a 10" diameter top hat. Refer to the manufacturer drawings for full front, top, and isometric dimensions and tolerances for planning and coordination.

• Top hat diameter: 10" (254 mm).
• Manufacturer drawings list nominal fixture weights for the IAL0310 configuration; consult them for exact values.

Materials and finish

The fixture is spun from 6061 aluminum and finished in Focus Industries' Black Texture polyester powder coat (finish code BL T). The manufacturer provides a range of standard and optional finishes for the IAL series.

• Material: 6061 aluminum.
• Standard finish for this SKU: Black Texture (BL T).

Mounting and wiring notes

The IAL series is supplied without a stem; fixtures include a 1/2" NPS base only. Mounting accessories such as stems, posts, canopies, junction boxes, and direct-burial posts are ordered separately.

Standard wiring and lens options are available from the manufacturer; confirm required accessories and wiring length when ordering.

• No stem included — 1/2" NPS base only; commercial series offers a 3" slip base version.
• Standard wire: 16" length, 18 AWG with black/white/green conductors (line-voltage power). Custom wire lengths are available per manufacturer instructions.
• Lens options: clear glass (standard) and frosted glass (FA89).
• Order mounting accessories and lenses separately as needed.

Before You Order

Confirm model number, finish, lamp choice, mounting accessories, and required voltage before ordering. The fixture ships without a stem and without a lamp; order stems/posts/canopies/lenses separately as needed.

• Verify you will supply an appropriate medium-base lamp and the correct line-voltage supply for your installation.
• Select mounting accessories (stem, post, canopy, J-box) and lens options separately — the fixture includes a 1/2" NPS base only.
