EnVision PL-H-ALM-BZ-DC – Decorative

Product Overview

The EnVision PL-H-ALM-BZ-DC is a decorative integrated LED low-voltage path light with an aluminum bronze finish. It combines selectable white color temperatures with RGB color scenes for flexible landscape and outdoor accent lighting.

This fixture is rated IP65 for wet locations, uses a 5W integrated LED, operates on 12–24V AC/DC, features a frosted polycarbonate lens and provides a 360° beam angle.

Key Features

• Integrated LED, 5W power
• 200 lumens (manufacturer specification)
• RGB plus 5 selectable white CCTs: 2700K, 3000K, 3500K, 4000K, 5000K
• 17 color/scene options accessible via push button
• Aluminum housing with bronze finish and frosted polycarbonate lens
• IP65 wet-location rating with watertight silicone ring
• Compatible with 12–24V AC/DC low-voltage drivers; manufacturer advises not to exceed 80% of transformer wattage
• Includes 6' (72") SPT-1W 20 AWG wire lead and 7" non-metallic spike

What this fixture does

The PL-H-ALM-BZ-DC is a decorative integrated LED path light intended for landscape and outdoor accent lighting. It provides omnidirectional illumination (360° beam) and supports both selectable white light and RGB color scenes for versatile outdoor lighting.

• Typical uses: landscape, walkways & pathways, security lighting, hospitality, multi-family, outdoor corridors, residential and commercial exteriors.
• Fixture type: low-voltage integrated LED path light with frosted polycarbonate lens.

Electrical and driver requirements

This model is designed for low-voltage systems and operates on 12–24V AC or DC. The integrated LED consumes 5W.

• Power: 5W integrated LED.
• Voltage: 12–24V AC/DC compatible.
• Transformer loading: manufacturer guidance—do not exceed 80% of the transformer's rated wattage when calculating maximum load.

Color and control options

The PL-H-ALM-BZ-DC combines RGB color capability with five selectable white color temperatures. Color and scene selection are performed at the fixture using an onboard push button.

• Selectable white CCTs: 2700K, 3000K, 3500K, 4000K, 5000K.
• RGB + scenes: 17 color/scene options including solid colors, blends and preset effects.
• Control: push-button selector located on the top of the stem; the cap is removed to access the switch.

Outdoor suitability and protection

The fixture is engineered for wet-location outdoor use and includes design features to resist water ingress and protect internal components.

• IP65 wet-location rating.
• Aluminum housing with watertight silicone ring and frosted polycarbonate lens.

Mounting, physical details and accessories

The PL-H-ALM-BZ-DC ships with a non-metallic spike and wire lead for in-ground installation. The manufacturer documents show stem and shade configurations in the product family and lists additional mounting accessories and optional stems/shades that may be ordered separately.

• Included: 6' (72") SPT-1W 20 AWG wire lead and 7" non-metallic spike.
• Reference stem height for the model family: 21".
• Available accessories (manufacturer offers): brass spike, surface mounts, stake covers, path light covers; stems and shades may be sold separately.
• Finish: Bronze.

Before You Order

Verify model, finish and the required stem/shade configuration before ordering since stems and shades may be sold separately.

• Confirm transformer capacity — total fixture load should not exceed 80% of transformer wattage.
• Confirm voltage compatibility (12–24V AC/DC) for your system.
